HP OMEN Maintenance And Service Manual page 35

Item Component
For use in Japan
For use in Belgium
For use in Korea
For use Internationally
For use in Slovenia
For use in Israel
For use in Switzerland
For use in Canada
For use in Nordic Regions
For use in Czech/Slovakia
(3) TouchPad cable
(4) TouchPad click button board
(5) Speaker (includes wire connected left and right speakers)
(6) Power button board
(7) USB board
For units equipped with NVIDIA N17P (GTX1050/GTX 1050Ti)
For units equipped with NVIDIA N17E (GTX1070/GTX 1060) and AMD R17M (RX580)
(8) Power in connector (cable is spared separately as 931561-001)
For products equipped with a 150 W adapter, and NV N17P (GTX 1050/GTX 1050Ti)
processors
For products equipped with a 230 W adapter, and NV N17E (GTX 1070/GTX 1060) and AMD
R17M (RX 580) processors
(9) Power in connector bracket ( for products equipped with a 150 W adapter only. Products
with a 230 W adapter do not have a bracket)
(10) System board (includes processor and replacement thermal material):
All system boards use the following part numbers:
xxxxxx-001 Non-Windows operating systems
xxxxxx-601 Windows 10 operating systems
NVIDIA N17E-G2 (GeForce GTX 1070), 8 GB i7-7700HQ
NVIDIA N17E-G1 (GeForce GTX 1060), 6 GB i7-7700HQ
NVIDIA N17P-G1 (GeForce GTX 1050Ti), 4 GB i7-7700HQ
NVIDIA N17P-G0 (GeForce GTX 1050), 4 GB i7-7700HQ
NVIDIA N17P-G0 (GeForce GTX 1050), 4 GB i5-7300HQ
NVIDIA N17P-G0 (GeForce GTX 1050), 2 GB i7-7700HQ
NVIDIA N17P-G0 (GeForce GTX 1050), 2 GB i5-7300HQ
NVIDIA N17E-G1 (GeForce GTX 1060), 6 GB i5-7300HQ
Spare part number
931691-291
931691-A41
931691-AD1
931691-B31
931691-BA1
931691-BB1
931691-BG1
931691-DB1
931691-DH1
931691-FL1
931594-001
931594-001
931598-001
931590-001
931588-001
931589-001
926204-002
926564-001
931582-001
929515-xxx
929516-xxx
929517-xxx
929518-xxx
929519-xxx
929520-xxx
929521-xxx
937746-xxx
Computer major components 23
