Setting A Station Name - Cabletron Systems SPECTRUM TRMMIM User Manual

Ring Map
Utilization
The percentage of the total usable bandwidth (4 or 16 Mb) that is currently being
used by the station. This field will update after each polling interval.
Performance and Errors
Error and performance statistics for the selected station are displayed according
to the currently selected calculation mode. Statistics displayed are:
•
•
•
•
•
•
•
•
•
•
•
•
See

Setting a Station Name

Using the Ring Map window, you can administratively assign a name to any
station on the monitored ring network.
To do so:
1. Click mouse button 3 on any station label in the map.
2. Drag down to Set Name, and release. The Set Station Name window,
3. In the Enter Name text field, enter a name (up to 10 ASCII characters) for the
4. Click on
3-8
Frames
Bytes
Line
Burst
AC
Abort Seq
Internal
Lost Frames
Congestion
Frame Copied
Token
Frequency
Viewing the Error Table,
Figure 3-4, will appear.
Figure 3-4. Set Station Name Window
selected station.
. The new name will be set at the station.
page 3-14, for detailed definitions of these statistics.
Viewing Station-specific Information
