PENDULUM
JIGSAW
810W
INSTRUCTION MANUAL
SPECIFICATIONS
Input Power:
230-240V~50Hz
Motor:
810W
No Load Speed
800-2,900/min
Stroke Depth:
22mm
Bevel:
+/- 45°
Blade Fitment:
Bayonet
Cutting Capacities:
Timber 80mm
Plastic 12mm
Mild Steel 8mm
Weight:
2.4kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: saw blades,
dust extraction adaptor, carbon brushes.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
WHAT'S IN THE BOX
Jigsaw
METAL BLADE
TIMBER BLADE
TIMBER BLADE
3 x Cutting Blades
Parallel Guide
Dust Extraction Adaptor
Hex Key
JSW-8100
1017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JSW-8100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito JSW-8100

  • Page 1 Weight: 2.4kg ozito.com.au Dust Extraction Adaptor Hex Key JSW-8100 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law. WARRANTY YOU MUST RETURN THE PRODUCT...
  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION PENDULUM JIGSAW 1 Variable Speed Dial 8 Guide Roller 1. CHANGING THE BLADE 2 Worklight Switch 9 Pendulum Action Selector 3 Lock On Button 10 Adjustable Shoe WARNING! ENSURE THE SAW IS SWITCHED OFF AND 4 On/Off Trigger 11 Soft Grip Handle DISCONNECTED FROM THE POWER SUPPLY BEFORE...
  • Page 3: Attaching The Accessories

    2. ADJUSTING SHOE ANGLE 3. ATTACHING THE ACCESSORIES The angle of the shoe can be adjusted to allow for bevel cuts Attaching the Parallel Guide between 0 and 45°. The parallel guide assists in cutting in a line parallel to an edge. 1 Loosen the 2 screws at the 1 Unscrew the 2 guide bottom of the jigsaw using...
  • Page 4: Operation

    OPERATION 4. CONTROLS 5. CONTROLS CONTINUED Adjusting the Cutting Speed CAUTION! TO REDUCE THE RISK OF ELECTRICAL The cutting speed should be adjusted to match the material of the SHOCK, THE USE OF A RESIDUAL CURRENT DEVICE workpiece. In general, use faster speeds for softer materials. (RATED 30mA OR LESS) IS RECOMMENDED.
  • Page 5 CAUTION! ENSURE HANDS AND FINGERS ARE KEPT WELL AWAY FROM THE BLADE AND THE CUTTING PATH AT ALL TIMES TO AVOID INJURIES. 5 Move jigsaw forward with light pressure. Allow the blade to stop before lifting the jigsaw away. JSW-8100...
  • Page 6: Troubleshooting

    OPERATION TROUBLESHOOTING Excessive sparking visible through the housing air vents and/or the jigsaw failing to operate 9. POCKET CUTTING May indicate the carbon brushes have worn out and need to be replaced. Carbon brushes should only be replaced by a qualified electrician or power tool repairer.
  • Page 7: Maintenance

    Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the jigsaw by an unauthorised person or by mishandling of the jigsaw.
  • Page 8: Electrical Safety

    ELECTRICAL SAFETY WARNING! The power supply for this product should be protected by a residual current device (rated at 30mA or less). A When using mains-powered tools, basic safety precautions, including the residual current device reduces the risk of electric shock. following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage.
