PENDULUM
JIGSAW
620W
INSTRUCTION MANUAL
SPECIFICATIONS
Input Power:
230-240V~50Hz
Motor:
620W
No Load Speed
800-3000spm
Stroke Depth:
20mm
Bevel:
+/- 45°
Blade Fitment:
Bayonet
Cutting Capacities:
Timber 85mm
Mild Steel 8mm
Plastic 12mm
Weight:
2.1kg
ozito.com.au
WHAT'S IN THE BOX
Jigsaw
Blade
Dust Extraction Adaptor
Splinter Guard
Parallel Guide
JSW-6100
Advertisement
Table of Contents
Related Manuals for Ozito JSW-6100
Summary of Contents for Ozito JSW-6100
- Page 1 SPECIFICATIONS Blade Input Power: 230-240V~50Hz Motor: 620W No Load Speed 800-3000spm Stroke Depth: 20mm Bevel: +/- 45° Dust Extraction Adaptor Blade Fitment: Bayonet Cutting Capacities: Timber 85mm Mild Steel 8mm Plastic 12mm Weight: 2.1kg ozito.com.au Splinter Guard Parallel Guide JSW-6100...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION PENDULUM JIGSAW 1 Variable Speed Dial 7 Soft Grip Handle 1. CHANGING THE BLADE 2 Lock On Switch 8 Pedulum Action Selector 3 On/Off Switch 9 Guide Roller WARNING! ENSURE thE SAW IS SWItChED Off AND 4 Blade Lock 10 Dust Blower Switch DISCONNECtED fROM thE POWER SUPPLy bEfORE... -
Page 3: Attaching The Accessories
2. ADJUSTING SHOE ANGLE 3. ATTACHING THE ACCESSORIES The angle of the shoe can be adjusted to allow for bevel cuts between Attaching the Parallel Guide 0 and 45°. The parallel guide assists in cutting in a line parallel to an edge. 1 Push the shoe 1 Unscrew the guide locking lever to the... -
Page 4: Operation
OPERATION 4. DUST EXTRACTION 5. CONTROLS A dust extractor can be fitted to the jigsaw dust extractor adaptor to CAUtION! tO REDUCE thE RISk Of ELECtRICAL remove dust and chips while cutting. The adaptor can also be removed ShOCk, thE USE Of A RESIDUAL CURRENt DEvICE if it gets in the way. - Page 5 6. CONTROLS CONT 7. CUTTING Adjusting the Cutting Speed 1 Ensure the correct blade is inserted into The cutting speed should be adjusted to match the material of the the blade lock and is workpiece. In general, use fasterer speeds for softer materials. secure.
-
Page 6: Pocket Cutting
A pocket cut is when you need to cut a hole in the middle of a workpiece 1 Drill a hole in the workpiece using a 12mm bit. 2 Pass the blade through the hole and begin the cut. JSW-6100... -
Page 7: Maintenance
Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the jigsaw by an unauthorised person or by mishandling of the jigsaw. -
Page 8: Electrical Safety
ELECTRICAL SAFETY WARNING! The power supply for this product should be protected by a residual current device (rated at 30mA or less). A When using mains-powered tools, basic safety precautions, including the residual current device reduces the risk of electric shock. following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage. -
Page 9: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZItO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0714...
