ADSL-DMT
Connection to the external telephone line interface.
Connections
Ethernet LAN Connection
The unit provides 10 Mbps Ethernet/IEEE 802.3 support. The
Ethernet LAN connection is through an 8-pin RJ45 10Base-T jack on
the rear of the unit.
ADSL-DMT WAN Connection
The router provides one ADSL port. ADSL provides high-speed data
rates. ADSL connectivity is through an 8-pin RJ45 jack on the rear of
the unit.
Console Connection
The console port provides asynchronous RS232 communications
connectivity to a terminal, computer, or modem. The console
connection is through an 8-pin RJ45 jack at the rear of the unit. The
console port is optionally used for configuration and management of
the router.
