Cabletron Systems Cabletron SmartSwitch Router 250 Quick Start Manual page 22

Adapter Setup
1. From the taskbar, click the Start button (located at the lower left
corner of your PC screen).
2. Point to Settings, click Control Panel, and double-click the
Network icon.
3. In the Network window, from the Configuration tab page, click
Add.
In the Select Network Component Type window, click
4.
Adapter, and then click Add.
5. In the Select Network Adapters window, select the network
adapter (manufacturer and adapter model) that matches your
hardware. Click Have Disk and follow the installation
instructions. Click OK.
Protocol Setup
From the taskbar, click the Start button (located at the lower left
1.
corner of your PC screen).
2. Point to Settings, click Control Panel, and double-click the
Network icon.
In the Network window, from the Configuration tab page, click
3.
Add.
21
