Specification And Warranty; Technical Specification - Pyronix ENFORCER V11 Installation Manual

ELECTRICAL
European rated voltage
European rated current
Capable operating voltage
Current
Rated frequency
Zone fuse rating
PSU
Radio frequency
ENFORCER BATTERY
Output instant voltage
Peak to peak ripple voltage
Battery low voltage cut off value
Type
CIE current when operating on battery backup
ENVIRONMENT
Physical dimensions (W x H x D)
Weight
Operating temperature
Nominal temperature
Storage temperature
I/O BOARD (IF CONNECTED)
Zones
Output voltage
Max current for PGM output
SAB outputs
Bus fuse
Aux fuse
SYSTEMS ANALYSIS: ZONES (MAX 66)
Wireless
Wired
Zone expansion modules

SPECIFICATION AND WARRANTY

11V (with no mains and battery fully charged)
ENFORCER V11 INSTALLATION GUIDE

TECHNICAL SPECIFICATION

230V AC -15/+10%
83mA
90 - 264V AC
222mA - 75mA
50/60Hz
T 2A (cannot replace)
Type A
868MHz, FM Transceiver Narrow Band
10mVpk
8.5V
NiMH 8 cell 2200mAh rechargeable battery
90mA
220 x 160 x 50mm
1025g
-10°C to +40°C
-10°C to +50°C
-20°C to +60°C
2 Wired (DEOL, SEOL)
13.2 VDC (nominal)
70mA
250mA Continuous Load
F500mA 250V Bus Fuse
F500mA 250V Aux Fuse
32
2
4 wired (8 wired zones each)
EURO-ZEM8, EURO-ZEM8+ or EURO-ZEM8+PSU
1 wireless (32 wireless zones)
EURO-ZEM32-WE
5
