Wireless ZEM header addressing
WIRELESS ZEM
ZEM32-WE
Wireless ZEM zone mapping
WIRELESS ZEM
ZEM32-WE
Please note: Wireless zones 35-66 can take upto 5 minutes to become active when armed.
Connecting an output expander
1 remote output expander can be connected to the Enforcer. The output expander allows 16 additional outputs.
Please note: The above shows the I/O board connected to a EURO-OEM8R8T. If the expander is a EURO-
OEM16R+PSU, the D2+ terminal must not be connected to the I/O board.
14
ADDRESS
ZEM address 00
ZEM address 01
ZEM address 02
ZEM address 03
ADDRESS
ZEM address 00
ZEM address 01
ZEM address 02
ZEM address 03
ENFORCER V11 INSTALLATION GUIDE
DEVICE A
DEVICE B
(0-3)
(4-7)
ON
OFF
ON
OFF
OFF
ON
ON
OFF
ZONES
D1- D2+
D3
D4
DEVICE C
(8-11)
OFF
OFF
OFF
OFF
35-42
43-50
51-58
59-66
PGM STB BELL
Z33 COM +12V Z34
