TECHNICAL DATA

Supported operating systems
Hardware requirements
Supported PLCs
Weight in kg
Dimensions (W x H x D) in mm
Protection type
Voltage supply
Power consumption
Operating temperature
Temperature storage/
transport
Relative humidity
Connection cable to the PC
Supported bus profiles
Supported transmission rate
of the bus connection to the
PLC
Supported transmission rates
USB
Max. number of connections
to MPI, PROFIBUS, PPI
ACCON-NetLink-USB compact
No restrictions (the driver for
SIMATIC ACCON-S7-NET is only
compatible with Windows XP,
2003R2, 7, 2008R2, 8.1, 2012R2,
10)
USB interface
S7-200, S7-300, S7-400
ca. 0.11
64 x 40 x 17
IP 20
5 VDC
USB 500 mA
0 °C to 60 °C
-20 °C to 90 °C
Operating 5 % to 85 % at 30 °C
Storage 5% to 93% at 40 °C
USB cable (3 m)
MPI, DP, standard, Universal
(DP/FMS), user-defined with
automatic detection, PPI
9.6 Kbps to 12 Mbps with
automatic detection
12 Mbps (USB 1.1) und
480 Mbps (USB 2.0)
32
