Assignment USB interface
Pin
1
2
3
4
Table 5: Pin assignment USB
The ACCON-NetLink-USB compact is supplied with a shielded 3 m USB
2.0 cable. The cable has an USB plug type A.
The length of a connection between PC and ACCON-NetLink-USB
compact must not exceed 3 m or the voltage drop in the cable gets too
high. When bridging longer distances please use an USB hub with
external voltage supply.
Updates on the Internet:
You can find the latest drivers and firmware versions on
www.deltalogic.de in the download section.
ACCON-NetLink-USB compact
Signal Meaning
VCC 5 VDC
D- Data -
D+ Data+
GND Ground
