SKU# 1001 375 582
Model #74032/HD-G2
USE AND CARE GUIDE
LED FLAT PANEL FIXTURE
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED Flat Panel Fixture. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Commercial Electric!

Advertisement

loading
Need help?

Need help?

Do you have a question about the 74032/HD-G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Commercial Electric 74032/HD-G2

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED Flat Panel Fixture. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ........2 Safety Information .
  • Page 3: Pre-Installation

    Pre-Installation TOOLS REQUIRED Phillips Power Drill 1/2 in. Drill Bit screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Mounting Plate 3/16 in. Toggle Bolts Wire Nuts Screws #8-32 x 1 in. Wiring Cover Wiring Cover Screws LIGHTING DISTRIBUTION Distance Center Beam...
  • Page 4: Installation

    Installation (T-Bar Ceiling) Preparing for Installation Attaching the Mounting Plate □ Prepare the wiring cover (EE) supplied in the hardwire kit. □ Connect the line voltage wire (black) to the building power supply with the wire nuts (CC). □ Attach the conduit connector (not included). □...
  • Page 5 Ceiling Wall Installation Re-attaching the Mounting Plate Wire Identification □ Feed the junction box wires through the center of □ Turn OFF the main power at the circuit breaker the mounting bracket plate (AA) hole. before installing the fixture. □ Re-attach the mounting plate (AA) by inserting the □...
  • Page 6 Installation (continued) Connecting the Swing Arms □ Insert the swing arm’s key hole slot into the mounting bracket plate’s (AA) hanging screw. Attaching the Panel Light □ Feed the junction box and fixture wires through the mounting bracket plate’s center hole. □...
  • Page 7 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
  • Page 8 GRACIAS Agradecemos la confianza que ha depositado en Commercial Electric a través de la compra de esta Lámpara LED de pantalla plana. Nos esforzamos por crear continuamente productos de calidad diseñados para mejorar su hogar. Visítenos en línea para ver nuestra línea completa...
  • Page 9 Tabla de contenidos Tabla de contenidos ....... . . 1 Información de Seguridad .
  • Page 10 Pre-Instalación HERRAMIENTAS REQUERIDAS destornillador taladro Broca de 1/2 pulg. de cruz eléctrico PIEZAS INCLUIDAS NOTA : Piezas no mostradas a tamaño real. Pieza Descripcción Cantidad Placa de montage (8,07 in. x 9,8 in. x 0,47 in.) 3/16 pulg. Perno de palanca Tuercas de Cable Tornillos #8-32 x 1 in.
  • Page 11 Instalación (T-Bar Techo) Preparación para la instalación Colocación de la placa de montaje □ Prepare la cubierta del cableado (EE) suministrada en el kit □ Conecte el cable de voltaje de línea (negro) a la de cableado. fuente de alimentación del edificio con las tuercas □...
  • Page 12 Instalación en la pared del techo Re-Instalando la Placa de Montaje Identificación de cables □ Introduzca los cables de la caja de conexiones a través del □ Desconecte la alimentación principal del disyuntor antes de centro del agujero de la placa de soporte de montaje (AA). instalar el aparato.
  • Page 13 Instalación (acondicionada) Conexión de los brazos oscilantes □ Inserte la ranura del orificio del brazo oscilante en el tornillo de sujeción de la placa del soporte de montaje (AA). Colocación del panel de luz □ Alimente la caja de conexiones y los cables del accesorio a través del orificio central de la placa del soporte de montaje.
  • Page 14 Preguntas, problemas, piezas que faltan ? Antes de regresar a la tienda, llame a Commercial Electric Servicio al Cliente 8 a.m. - 7 p.m., EST, Lunes - Viernes, 9 a.m. - 6 p.m., EST, Sábado 1-877-527-0313 HOMEDEPOT.COM Conserve este manual para uso futuro.
