FPIM Specifications
Transmitter power parameters are listed in Table A-2.
50/125 m
fiber
62.5/125 m
fiber
100/140 m
fiber
Error Rate
The link distance is up to 2 kilometers on the multimode fiber-optic cable as
specified by ANSI MMF-PMD.

FPIM-02 and FPIM-04

The FPIM-02 has an RJ-45 connector supporting an Unshielded Twisted Pair
(UTP) connection. The FPIM-04 has an RJ-45 connector supporting a Shielded
Twisted Pair (STP) connection. The pinouts for both are listed in Table A-3.
The link distance is up to 100 meters on unshielded twisted pair cable as specified
by ANSI TP-PMD.
A-2
Table A-2. Transmitter Power Parameters
Parameter Typical Value
-13.0 dBm
-10.0 dBm
-7.0 dBm
Better than 10
Table A-3. FPIM-04 Pinouts
Pin Number Represents
1 Transmit+
2 Transmit-
3 NA
4 NA
Worst Worst Case
Case
-15.0 dBm 13.0 dB
-12.0 dBm 16.0 dB
-9.0 dBm 19.0 dB
-10
Pin Number
5
6
7
8
Typical
Budget Budget
17.5 dB
20.5 dB
23.5 dB
Represents
NA
NA
Receive+
Receive-
