- Page 1 Sit and Stand Mobile Workstation Instruction Manual SKU: CART-V06A Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-v06a help@vivo-us.com www.vivo-us.com 1-800-371-5654...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 Screw casters (7) into underside of base. Tighten with wrench (F). STEP 2 Assemble poles to base using x9 M6x12 screws (C) and x6 M6x15 screws (D), making sure the pole with the release lever is installed in the center.
- Page 4 STEP 3 Install support plate (3) to poles using x6 M6x12 screws (C). Tighten with 4mm Allen wrench (E). STEP 4 Assemble desktop (1) using x10 M5x12 screws (A). Secure release lever handle to desktop with x3 M5x12 screws (A).
- Page 5 STEP 5 Secure center pole to desktop (1) with x4 M5x20 screws (B). STEP 6 Install keyboard shelf brackets (2) to desktop using x6 M5x12 screws (A). Curved slots must be facing towards the front.
- Page 6 STEP 7 Mount keyboard shelf (4) to brackets with x6 M5x12 screws (G). STEP 8 Ensure the handle is correctly pulling on the release cable. If the release cable tension is too high (height will not lock) or too low (desk will not raise or lower), turn the nuts at the end of the black tube near the handle to adjust the tension.
- Page 7 STEP 9 To adjust height, lift release lever handle (5).
- Page 8 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
