ASH BY U P H O L ST E RE D P LAT FORM QU E E N B ED - ASS EMBLY IN ST RU CT ION S
CARE INSTRUCTIONS:
1. DUST OFTEN USING A CLEAN, SOFT, DRY, AND LINT-FREE CLOTH.
2. BLOT SPILLS IMMEDIATELY, AND WIPE WITH A CLEAN, DAMP CLOTH.
3. DO NOT USE CHEMICAL CLEANSERS, ABRASIVES OR FURNITURE POLISH ON THE LACQUERED FINISH.
PARTS I N CLU DE D:
A
[1]
HEADBOARD
B
[1]
FOOTBOARD
C
[2]
SIDE RAILS
D
[3]
SLATS
E
CENTER LEGS
[3]
F
[2]
PLATFORM PANELS
TOO L S N E E D E D :
Phillips-head screwdriver (not included)
ASS E M B LY I N ST R U CT IO N S :
STEP 1:
Insert the Threaded Rods (1) into the posts of the
Headboard (A) and Footboard (B).
B
NO.
2
(1)
ITEM
1
3
4
5
Page 1 of 4
DESCRIPTION
Threaded Rod
5/16"
x
3"
Curved Slotted Washer
5/16"
Hex Nut
5/16"
x 12mm
Hex Wrench 12 mm
Screws 8 x 30 mm
A
QTY.
8 pcs.
8 pcs.
8 pcs.
1 pc.
24 pcs.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RH Baby&child 0313-13
Summary of Contents for RH Baby&child 0313-13
- Page 1 ASH BY U P H O L ST E RE D P LAT FORM QU E E N B ED - ASS EMBLY IN ST RU CT ION S CARE INSTRUCTIONS: 1. DUST OFTEN USING A CLEAN, SOFT, DRY, AND LINT-FREE CLOTH. 2.
- Page 2 AS H B Y UP HO LST E RE D P L AT FORM QU E E N B ED - ASS EMBLY IN ST RU CTI ON S STEP 2: Slide the Side Rails (C) onto the Headboard (A) and Footboard (B). Insert Curved Slotted Washers (2) and Hex Nut (3), and tighten with Hex Wrench (4).
- Page 3 ASH B Y U P H O L ST E R E D P L AT FOR M Q UE E N B ED - ASS EM BLY IN ST RU CT ION S STEP 4: Phillips-head Lay the Slats (D) between the Side Rails (C), screwdriver.
- Page 4 ASH BY U P H O L ST E RE D P LAT FORM QU E E N B ED - ASS EMBLY IN ST RU CT ION S STEP 6: The adjustable levelers should be used when the object is placed on an uneven floor.
