RH Baby&child MARCELLE Instructions Manual

Hide thumbs Also See for MARCELLE:

Advertisement

Quick Links

Download this manual
Made in Vietnam
Distributed in the U.S.A. by:
Restoration Hardware Baby & Child
11640 Harrel St. Suite B
Mira Loma, CA 91752
www.rhbabyandchild.com
Distributed in Canada by:
Restoration Hardware Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia V6E4N7
WARNING: Read all
instructions before assembling this
product. KEEP INSTRUCTIONS
FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to the
address above. Include the product model number, color, and a brief description of the part. Call 1-800-762-1751.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft, dry cloth.
Blot spills immediately and wipe with a clean damp cloth. If the crib is to be stored, store in a cool dry place and carefully
package all original hardware to protect from loss.
TOOLS AND INSTALLATION
Tools Necessary: Allen Key (included)
NOTE: It may be easier to assemble product with two people.
NOTE: When inserting bolts, turn clockwise until tight. Then loosen
completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly
1
3
-
of a turn. After crib is
2
4
Page 1 of 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the MARCELLE and is the answer not in the manual?

Questions and answers

Related Manuals for RH Baby&child MARCELLE

Summary of Contents for RH Baby&child MARCELLE

  • Page 1 Made in Vietnam Distributed in the U.S.A. by: Restoration Hardware Baby & Child 11640 Harrel St. Suite B Mira Loma, CA 91752 www.rhbabyandchild.com Distributed in Canada by: Restoration Hardware Canada, Inc. 1500-1055 West Georgia Street Vancouver, British Columbia V6E4N7 WARNING: Read all instructions before assembling this product.
  • Page 2 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING: Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death. •...
  • Page 3 IMPORTANT SAFETY INFORMATION FOR CRIBS CAUTION: ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES WITH A THICKNESS NOT EXCEEDING 6 INCHES. WARNING · DO NOT use this crib if the enclosed or attached instructions cannot be strictly adhered to.
  • Page 4 IMPORTANT SAFETY INFORMATION FOR TODDLER & DAY BEDS WARNING: ENTRAPMENT / STRANGULATION HAZARD Infants have died in toddler beds from entrapment and strangulation. Failure to follow these warnings and the assembly instructions could result in serious injury or death. NEVER use bed with children under 15 months. NEVER place bed near windows where cords from blinds or drapes may strangle a child.

  • Page 5: Item Identification

    ITEM IDENTIFICATION For ease of identification, all parts are labeled to correspond to the step number in which the part is used. Step #1 Leg and side panel assembly. Panel and rail frame assembly (Page 6). Step #2 Mattress support arm assembly. Stabilizer rail assembly.
  • Page 6 STEP #1 LEG AND SIDE PANEL ASSEMBLY PANEL AND RAIL FRAME ASSEMBLY DETAIL A STEP #1.1 Gently lay the side panels on their backs on a flat and non abrasive surface. STEP #1.2 Align and insert the threaded rod of the leg into the holes and turn clockwise to tighten.
  • Page 7 STEP #2 DETAIL C MATTRESS SUPPORT ARM ASSEMBLY STABILIZER RAIL ASSEMBLY LOCK HEX NUT WASHER MATTRESS HEIGHT ADJUSTMENT STEP #2.1 ALLEN BOLT Lay Mattress Support flat with Stabilizer Rail on each side. (BB) NOTE: Each end of the arm of the Mattress Support has a hole for the bolt to pass through that corresponds to the holes located in the frame of the Mattress Support.
  • Page 8 STEP #3 INSTALLATION OF STABILIZER RAILS INTO THE SIDE PANEL STEP #3.1 On inside face of both side panels are pre-installed metal brackets, designed to hold the stabilizer rails. Set both ends of the stabilizer rails into brackets, as illustrated in DETAIL E DETAIL E.
  • Page 9 STEP #4 RAIL FRAME ASSEMBLY STEP #4.1: Please repeat procedure in step #1.4 for DETAIL H. DETAIL H After assembly, re-tighten all bolts to a snug fit. DO NOT OVER TIGHTEN. HARDWARE NEEDED FOR STEP #4: (AA) 1/4" X 1-3/4" BOLT = 4 PCS LOCK WASHER = 4 PCS PLAIN WASHER = 4 PCS ALLEN WRENCH = 1 PC...
  • Page 10 STEP #5 TODDLER RAIL ASSEMBLY STEP #5.1: Remove the rail frames of the crib by loosening all the bolts installed as well as the mattress support. DETAIL I STEP #5.2: Gently tilt the crib and release the bolts underneath the metal brackets holding the stabilizer rails.
