The Tech Works VPSS-L is a two-gang correctional/industrial grade
Passive Intercom Speaker Station designed for the most demanding
environments. The speaker/microphone is moisture resistant, includes a 25
Volt matching transformer, and employs three steel barriers to protect it
from tampering and vandalism. The integral "Call-In" switch is hermetically
sealed and utilizes a limited travel actuator to protect from excessive force
or moisture. An ultra-bright LED call confirmation light built into the button
lets the caller know that their call has been placed. The 12-gauge stainless
steel faceplate and tamperproof mounting hardware makes the VPSS-L
almost indestructible.
We've selected the best and most popular 25V speakers to pair with the
products we build. The System 2 is a wall mount speaker. Complete with
wall mounting steel enclosure.
The System 21 is a round ceiling mount speaker which includes a backbox
and all required mounting hardware. This unit is designed to be cut into
existing hard lid ceilings and has a 25V speaker.
The System 5 is a drop in ceiling speaker which replaces a standard size
acoustic ceiling tile. The System 5 includes a fire-resistant back enclosure
and 2V speaker assembly.
PA-16HT is a weatherproof Paging Loudspeakers for use in outdoor areas.
All metal construction and baked enamel finish make it small, loud and
durable. The PA-16HT includes a 25V transformer and power selection.
The Tech Works CAT6-* ("*" specify Length) is an EIA 568B standard
computer network Patch Cable designed to connect our Tech Works
products together. These units are designed for the systems integrator to
make installation Plug and Play.
The Tech Works PS-2437A is a regulated computer grade power supply
capable of providing 3.75 Amps of power at 24-Volts DC to any of our
products. A 6-foot removable power cord with a North American standard
Edison connector is included along with a metal mounting bracket to allow
the unit to be screwed to the wall or under a counter.
The Tech Works PC-* ("*" specify Length) is a Power Patch Cable designed
to connect our Tech Works Collaborative Intercom (CI-Buss) and PA-Buss
products together. These units are designed for the systems integrator to
make installation Plug and Play. 18-gauge power cord is made with 5.5 mm
barrel connectors on each end for connecting 24 VDC power from one unit
to the next.
1/24/2021
Tech Works MC-IP-Series System Planning & Installation Manual
Page 7 of 32
