The ATL431EVM is an adjustable voltage reference evaluation module that demonstrates the ATL431
integrated circuit from Texas Instruments (TI).
The ATL431 is a low-power counterpart to the TL431 and TLV431, having lower minimum cathode
current (Ik
= 35 μA vs 0.1/1.0 mA). Like TL431, ATL43x is used in conjunction with its key
min
components to behave as a single voltage reference, error amplifier, voltage clamp or comparator with
integrated reference.
The ATL431 can be operated and adjusted to cathode voltages from 2.5 V to 36 V, making this part
optimum for a wide range of end equipment in industrial, auto, telecom, and computing. In order for
this device to behave as a shunt regulator or error amplifier, > 35 μA (I
the cathode pin. Under this condition, feedback can be applied from the Cathode and Ref pins to
create a replica of the internal reference voltage.
The EVM is configured with resistor options to set the cathode current, resistor options to set the
cathode voltage, and load capacitor options to check stability. A test point can be connected to an
external power supply to provide power. All of the ATL431 input and output pins are accessible for
external connection via test points.
1.1
ATL431EVM Features
Multiple resistor options for cathode current setting
Multiple resistor options for cathode voltage setting
Open 0805 footprints for user resistor option
Multiple capacitor options for stability and transient response measurement
Test points for voltage measurement
Key Parameters
Programmable Cathode Voltage:
Applying voltages above the limitations given in
damage to your hardware.
Gerber (layout) files are available at www.ti.com.
SLVUAE7 – April 2015
Submit Documentation Feedback
ATL431 Adjustable Shunt Regulator EVM
Table 1. ATL431EVM Specification
Supply Voltage:
0 V – 40 V
2.5 V – 36 V
Cathode Current:
35 µA to 100 mA
Copyright © 2015, Texas Instruments Incorporated
CAUTION
Table 1
may cause permanent
ATL431 Adjustable Shunt Regulator EVM
User's Guide
SLVUAE7 – April 2015
(max)) must be supplied into
min
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ATL431 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments ATL431

  • Page 1 The ATL431 can be operated and adjusted to cathode voltages from 2.5 V to 36 V, making this part optimum for a wide range of end equipment in industrial, auto, telecom, and computing. In order for this device to behave as a shunt regulator or error amplifier, >...
  • Page 2 Overview www.ti.com Schematic The schematic for the ATL431EVM is illustrated in Figure Figure 1. ATL431EVM Schematic ATL431 Adjustable Shunt Regulator EVM SLVUAE7 – April 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated...
  • Page 3 Overview www.ti.com The PCB layout for the ATL431EVM is illustrated in Figure Figure 2. ATL431EVM PCB Layout SLVUAE7 – April 2015 ATL431 Adjustable Shunt Regulator EVM Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated...
  • Page 4: Electrostatic Discharge Warning

    Unpacking the EVM After opening the ATL431EVM package, ensure that the following is included: 1 pc. ATL431EVM board using one ATL431 Power Supply Setup and Functional Test A 40-V power supply capable of 100 mA of current is required.
  • Page 5 V and the desired cathode voltage (V ) to provide enough current for operation. The ATL431 needs > 35 µA in order to operate in the proper gain region for accurate regulation. Use Equation 1 to determine the cathode current.
  • Page 6: Test Modes

    OUTPUT Input 10NŸ 2.5NŸ 10µF 5.0V Figure 6. Test Circuit for I 10NŸ Figure 7. Test Circuit for Phase and Gain Measurement ATL431 Adjustable Shunt Regulator EVM SLVUAE7 – April 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated...
  • Page 7 Figure 9. Test Circuit for Stability Boundary Conditions 25NŸ OUTPUT Pulse Generator 50 Ÿ F = 100kHz Figure 10. Test Circuit for Pulse Response SLVUAE7 – April 2015 ATL431 Adjustable Shunt Regulator EVM Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated...
