Designator
R2, R4, R5, R6, R16, R18,
R19, R20, R30, R32, R33,
R34, R46, R48, R49, R50
R7, R8, R21, R22, R35,
R36, R51, R52
R10, R12, R13, R14, R24,
R26, R27, R28, R38, R40,
R41, R42, R54, R56, R57,
R58, R69, R86, R107,
R115, R116
R43, R44
R61, R62, R90, R91,
R103, R105, R110, R111,
R112
R65, R66, R67, R68, R70,
R71, R73, R74, R75, R76,
R79, R80, R81, R82, R83,
R84, R85, R87, R88, R89,
R92, R93, R94, R95, R96,
R97, R98, R99, R100,
R101
R72, R104
R108
R109
R113
R114
R117, R118
S1
S2
SH-J1, SH-J2, SH-J3, SH-
J4, SH-J5, SH-J6, SH-J7,
SH-J8, SH-J9
TP1, TP2, TP3, TP4, TP6,
TP7, TP8, TP9, TP10,
TP11, TP12, TP13
TP5, TP14
U1, U2, U3, U4
U5
U6
U7
U8
SBAU193E – JUNE 2011 – REVISED MAY 2021
Submit Document Feedback
Qty
Value
Description
16
1.00k
RES, 1.00 k, 1%, 0.1 W, 0603
8
10.0
RES, 10.0, 1%, 0.1 W, 0603
21
0
RES, 0, 1%, 0.1 W, AEC-Q200
Grade 0, 0603
2
20.0k
RES, 20.0 k, 1%, 0.1 W, 0603
9
10.0k
RES, 10.0 k, 1%, 0.1 W, AEC-
Q200 Grade 0, 0603
30
49.9
RES, 49.9, 1%, 0.1 W, 0603
2
1.00
RES, 1.00, 1%, 0.1 W, 0603
1
120k
RES, 120 k, 1%, 0.1 W, 0603
1
0.22
RES, 0.22, 1%, 0.1 W, AEC-
Q200 Grade 0, 0603
1
5.11
RES, 5.11, 1%, 0.1 W, AEC-
Q200 Grade 0, 0603
1
100k
RES, 100 k, 1%, 0.1 W, 0603
2
6.65k
RES, 6.65 k, 1%, 0.1 W, 0603
1
Switch, Tactile, SPST-NO,
0.05A, 12V, SMD
1
Switch, Slide, SPDT 100 mA,
SMT
9
1x2
Shunt, 100 mil, Flash Gold,
Black
12
Test Point, Multipurpose, Red,
TH
2
Test Point, Multipurpose, Black,
TH
4
1.1 nV/rtHz Noise, Low Power,
Precision Operational Amplifier,
4.5 to 36 V, -40 to 125 degC, 8-
pin SOP (DDA8), Green (RoHS
& no Sb/Br)
1
Analog to Digital Converters
- ADC 16B,8Ch,Sim Sampling
Bipolar Inp ADC
1
5ppm/C High-Precision Voltage
Reference with Integrated High-
Bandwidth Buffer, DGK0008A
(VSSOP-8)
1
I2C BUS EEPROM (2-Wire),
TSSOP-B8
1
36V, 1A, 4.17μVRMS,
RF Low-Dropout (LDO)
Voltage Regulator, RGW0020A
(VQFN-20)
Copyright © 2021 Texas Instruments Incorporated
Bill of Materials, Layout, and Schematic
Manufacturer
Part Number
RC0603FR-071KL
Yageo
RC0603FR-0710RL
Yageo
RMCF0603ZT0R00
Stackpole
Electronics Inc
RC0603FR-0720KL
Yageo
RMCF0603FT10K0
Stackpole
Electronics Inc
RC0603FR-0749R9L
Yageo
RC0603FR-071RL
Yageo
RC0603FR-07120KL
Yageo
ERJ-3RQFR22V
Panasonic
CRCW06035R11FKEA
Vishay-Dale
RC0603FR-07100KL
Yageo
RC0603FR-076K65L
Yageo
EVQPNF04M
Panasonic
CAS-120TA
Copal Electronics
SPC02SYAN
Sullins Connector
Solutions
5010
Keystone
5011
Keystone
OPA2211AIDDA
Texas Instruments
ADS8568SPM
Texas Instruments
REF6025IDGKR
Texas Instruments
BR24G32FVT-3AGE2
Rohm
TPS7A4700RGWR
Texas Instruments
ADS8568EVM-PDK Evaluation Module
21
