It is important to follow the correct color code when inserting the pins into the AMP connectors.
6. Plug the extension cables to the LED light heads.
7. Next, plug the other end of the cable into the Light Head Output Socket on the Flasher, see Figure 1.
Output Designation:
Output #1 :
Output #2 :
Output #3 :
Output #4 :
Output #5 :
Output #6 :
Output #7 :
Output #8 :
8. (Refer to Figure 5) Plug the Power / Control Harness into the Flasher. Connect the Red and Black wires
of the Power-In connector to +12V and ground terminals respectively. Insure that the Red power wire is
fused with a 15 Amp AUTO style fuse. Connect the Flash-Pattern program and the Interclear-pattern
program connectors to two momentary pushbutton switches, these switches can be used to program the
desired flash-pattern for regular operation and Interclear operation modes respectively.
Also, if the Active-High Interclear option is desired, connect the white wire to the Interclear Output on the
siren(if applicable). Connect the Green and Blue wires of the Mode Control Connector to +12V through two
user supplied SPST switches. These switches could be used to activate the Group B and Group A outputs
respectively.
Optional: Connect the Photocell Input connector of the wiring harness to the optional photocell
assembly P/N T08085 using the optional photocell extension cable P/N T08086.
Note: In case a photocell option is not desired, the Black and Green wires of the Photocell Input
connector should be shorted together.
NOTE
Group A, Left
Group A, Right
Group B, Left
Group B, Right
Group C, Left
Group C, Right
Group A, Left
Group A, Right
R
R
