10.1. Cleaning and Assembly of the Oven Door

Figure 10
Figure 10.1
Open the door
completely by
pulling the oven
door toward you.
Then, as shown
in Fig. 10.1,
pull the hinge
lock up with a
screwdriver
and perform
the unlocking
operation.
To replace the oven door again; reverse the procedure for removing
the door.
Figure 10.2
As shown in Fig.
10.2, bring the
hinge lock to
the maximum
angle. Bring
both hinges that
connect the oven
door to the oven to
the same position.
GB
Figure 11
Figure 11.1
Then, close the
oven door you have
opened so that
it shall lean against
the hinge lock
as shown in
Fig. 11.1.
31
Figure 11.2
To remove the oven
door, hold the door
with both hands
when it is at a
close level to the
closed position,
and pull it up as
shown in Fig. 11.2
.
