OWNER'S MANUAL
Submersible Sewage Pump
Automatic and manual models.
Single phase power only — 115 volt.
SKM50A SERIES
Installation/Operation/Parts
For further operating, installation,
or maintenance assistance:
Call 1-888-957-8677
HYD857 (10/27/08)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hydromatic SKM50A Series
Summary of Contents for Hydromatic SKM50A Series
- Page 1 Submersible Sewage Pump Automatic and manual models. Single phase power only — 115 volt. 740 East 9th Street Ashland, OH 44805 Phone: 1-888-957-8677 Fax: 1-888-840-7867 Web Site: http://www.hydromatic.com SKM50A SERIES Installation/Operation/Parts For further operating, installation, or maintenance assistance: Call 1-888-957-8677 HYD857 (10/27/08)
-
Page 2: Repair Parts
Repair Parts PARTS LIST Ref. Part Ref. Part No. Description Req’d. Numbers No. Description Req’d. Numbers Cord, electric (20’) 21628B044 Screw, machine, flat head 07597A030 Cap, motor (stamped) 24431C061 10 Screw, cap, 5/16-18 x 3/4 19100A004 Screw, machine, hex head, 1/4 x 7/8 18475A003 11 Seal, type 6;... -
Page 3: Description And Application
Each pump is packaged separately in a carton marked National Electric Code (NEC-ANSI/NFPA 70). with a catalog number and Hydromatic engineering All pumps have a GROUND WIRE that is connected to number. -
Page 4: Limited Warranty
Your only remedy, and HYDROMATIC’s only duty, is that HYDROMATIC repair or replace defective products (at HYDROMATIC’s choice). You must pay all labor and shipping charges associated with this warranty and must request warranty service through the installing dealer as soon as a problem is discovered. No request for service will be accepted if received after the Warranty Period has expired. - Page 5 Installation 30” DIAMETER SIMPLEX...
-
Page 6: Maintenance
12. Check that the impeller turns freely. the nut snugly, but do not over tighten. The nut may 13. Replace oil in motor housing using only Hydromatic be tightened a little more after the connector has set submersible transformer oil. The oil should be about over a period of time. -
Page 7: Wiring Diagram
Name Plate ‘G’ marked on the cap. Surface 14. Put oil in the motor housing using only Hydromatic 5893 1008 submersible transformer oil, Part No. 24709110000. The oil should be about 1/2" above the surface of... -
Page 8: Dimensions And Performance
Dimensions and Performance...
