- Page 1 ASSEMBLY INSTRUCTIONS : STORAGE CHEST 37 INCH RTA Description : TC-937 Item No. ITEM NO.: TC-937 Printed in Vietnam REVISED SEP 24, 2014 - 1 -...
-
Page 2: Before Assembly
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish on your product. Protect the surface of the product with a cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: TC-937 Printed in Vietnam REVISED SEP 24, 2014 - 2 -... -
Page 3: Part List
Description Sketch Description Sketch BOLT Short screw (M6x30mm) (M4x15mm) Spring Long screw washer (M4x30mm) (ɸ6.5x11mm) Flat washer Allen key (ɸ6.5x13mm) Hinge ITEM NO.: TC-937 Printed in Vietnam REVISED SEP 24, 2014 - 3 -... - Page 4 Attach Back panel (B) and Front panel (D) to Side panel (E) with Bolts (1), and washers (2), (3), Tighten with Allen key (7). Attach Support bottom panel (C) to Back and front panel with Screw (6) as shown below. Tighten with a screwdriver. ITEM NO.: TC-937 Printed in Vietnam REVISED SEP 24, 2014 - 4 -...
- Page 5 Slide Bottom panel (F) into groove of the unit as shown below. Then attach Side panel (E) to the unit with bolts (1), washers (2) and (3). Tighten with Allen key (7). Attach top (1) to the unit with screw (5) as shown below. Tighten with a screwdriver. ITEM NO.: TC-937 Printed in Vietnam REVISED SEP 24, 2014...
- Page 6 STEP 3 Attach Hinges (4) to the unit with screws (5) as shown below. ITEM NO.: TC-937 Printed in Vietnam REVISED SEP 24, 2014 - 6 -...
