- Page 1 ASSEMBLY INSTRUCTIONS : BUNK BED Description : BD-80BUNKE, BD-80BUNKS AND BD-80BUNKR Item No. (PACKED IN SEPARATE BOX) ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015 - 1 -...
-
Page 2: Before Assembly
Strangulation Hazard: Never attach or hang items to any part of the bunk bed that are not designed for use with the bed for example, but not limited to hooks, belts, and jump ropes. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015 - 2 -... - Page 3 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Slat ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015 - 3 -...
- Page 4 Description Sketch Description Sketch Rail Lower Rail Lower Front Back Rail Upper Rail Upper Front Back Guard Rail Guard Rail Front Back Ladder ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015 - 4 -...
-
Page 5: Hardware List
Attach rail lower front (C) and rail lower back (D) to headboards lower (A) with bolts (1) and washers (2) and (3). Tighten with Allen key (4). ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015... - Page 6 Tighten with Allen key (4). Attach guard rail back (H) to rail upper back (F) with bolts (5) and washers (7) and (8), as show below. Tighten with Allen key (4). ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015...
- Page 7 Tighten with Allen key (4). Attach guard rail front (G) to rail upper front (E) with bolts (5), washers (7) and (8) as shown below. Tighten with Allen key (4). ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015...
- Page 8 STEP 5 Insert dowels (11) to headboards (A). Then insert unit (From step 4) onto the dowels (11). ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015 - 8 -...
- Page 9 Attach ladder (J) to rail lower front (C) with bolts (5) and washers (7) and (8). Tighten with Allen key (4). Attach ladder (J) to rail upper front (E) with screws (10), as shown below. Tighten with a screwdriver. ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam...
- Page 10 Attach slats (I) to rail upper front (E) and rail upper (F) with screws (9), as shown below. Tighten with a screwdriver. Attach slats (I) to rail lower front (C) and rail lower (D) with screws (9), as shown below. Tighten with a screwdriver. ITEM NO : BD-80BUNKE, BD-80BUNKS, BD-80BUNKR Printed in Vietnam ISSUED SEP 04, 2015 - 10 -...
