- Page 1 ASSEMBLY INSTRUCTIONS T-42DPT AND T-30P T-42DPT AND T-27B T-42DPT AND T-11B Description : 42 IN DROPLEAF TOP ONLY Item No. : T-42DPT AND T-30P OR T-27B OR T-11B (PACKED IN SEPARATE BOX) - 1 -...
-
Page 2: Before Assembly
BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. -
Page 3: Part List
PART LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Mounting Plate Wood slide RT LIST PART LIST HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch... - Page 4 STEP 1 Attach the mounting plate (B) to the pedestal with bolts (1), and washers (2) and (4) as shown below. Tighten with Allen key (5).
- Page 5 STEP 2 Carefully place the pedestal on the bottom side of the table top. Attach the top (A) to mounting plate with bolts (1), and washers (4) and (3) as shown below. Tighten with Allen key (5). - 5 -...
- Page 6 STEP 3 Hold the drop leaf push and slide the wooden piece from underneath the table top. To lower the drop leaf, carefully hold the drop leaf with one hand and slide the wooden piece from underneath the table top towards the center of the top. Then, gently lower the leaf and place in the down position - 6 -...
