Summary of Contents for International Concepts T-4060XBF
- Page 1 ASSEMBLY INSTRUCTIONS Description : COUNTRY FRENCH BUTTERFLY LEAF TABLE Item No. : T-4060XBF ITEM NO.: T-4060XBF Printed in Vietnam REVISED DEC 10, 2014 - 1 -...
- Page 2 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Flat washer Lock washer (8.5x19mm) (8.5x13mm) Hexagon nut Wrench (M8x13mm) (M13mm) ITEM NO.: T-4060XBF Printed in Vietnam REVISED DEC 10, 2014 - 2 -...
- Page 3 STEP 1 Attach legs (B) to the top (A) using washers (1) and (2) and nuts (3) as shown below. Tighten with the wrench (4). ITEM NO.: T-4060XBF Printed in Vietnam REVISED DEC 10, 2014 - 3 -...
- Page 4 STEP 3 Place the leaves in the center of the open table top. Push the table top closed. Lock the mechanism underneath 2 sides of the table top as shown below. ITEM NO.: T-4060XBF Printed in Vietnam REVISED DEC 10, 2014...
