- Page 1 Edge Multipoint and Quickbridge Hardware Installation Guide Products Covered --> Edge - MP-1015-CPE - MP-1025-CPE - MP-1035-CPE - MP-1015-BS3 - MP-1025-BS3 - QB-1015-LNK (2 x QB-1015-EPR) - QB-1025-LNK (2 x QB-1025-EPR) - QB-1035-LNK (2 x QB-1035-EPR)
- Page 2 Disclaimer Proxim reserves the right to revise this publication and to make changes in content from time-to-time without obligation on the part of Proxim to provide notification of such revision or change. Proxim may make improvements or changes in the product(s) described in this guide at any time.
-
Page 3: Table Of Contents
Package Contents ............. 5 Getting Started . - Page 4 14 dBi Dual Polarized Sector Antenna............33 15.5 dBi Dual Polarized Sector Antenna .
-
Page 5: Package Contents
Package Contents Each shipment includes the items listed in the following table. Please verify that you have received all the parts in this shipment, prior to installation. What’s in the kit Image MP-1015-CPE MP-1025-CPE MP-1035-CPE MP-1015-BS3 MP-1025-BS3 QB-1015-LNK (2 x QB-1015-EPR) QB-1025-LNK (2 x QB-1025-EPR) QB-1035-LNK... - Page 6 Package Contents What’s in the kit Image Mounting Kit and Hardware The mounting kit includes the following: Full axis mounting kit Pair of hose clamps Quick Installation Guide Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 7: Getting Started
Getting Started 2.1 Power-Up To Power on the device, perform the following steps: 1. Connect the OUT / POE port on the PoE and the Ethernet Port of the device using a standard Cat5e cable terminated with RJ45 connectors. 2. Connect the IN / LAN port on the PoE and the NIC port of a computer. 3. -
Page 8: Device Overview
Device Overview This section provides the hardware overview and installation procedure for the following product(s): MP-1015-CPE • MP-1025-CPE • • MP-1035-CPE MP-1015-BS3 • MP-1025-BS3 • • QB-1015-LNK (2 x QB-1015-EPR) • QB-1025-LNK (2 x QB-1025-EPR) QB-1035-LNK (2 x QB-1035-EPR) • 3.1 Edge 1015, 1025 and 1035 Hardware Overview Device Model Description... -
Page 9: Gigabit Ethernet Ports
Device Overview The features of the above devices are tabulated as below: A detailed description about the various components of the device are explained in the following sections. Item Features Description Ethernet Port • PoE IN and Data • Debugging and Management Grounding Point •... -
Page 10: Grounding Points
Device Overview • Ethernet Port supports the following features: 1. Auto MDI-X, auto configuration and fixed speed/duplex configurations. 2. Jumbo frames of size up to 9 k bytes. Recommended Ethernet Cable Specifications Type Cat5e, Cat6, STP, 24 AWG, UL rated, Shielded, UV Resistant and outdoor-rated Impedance 100 ohms Cable Length... -
Page 11: Device Installation
To make optimal use of the device, you must find a suitable location to install the hardware. The range of the radio device largely depends upon the position of the antenna. Proxim recommends you do a site survey, observing the following requirements, before mounting the hardware. - Page 12 2. Please make a note of the Ethernet addresses, the MAC addresses and the serial number. These addresses may be used when configuring the device. Note that the serial number helps you to seek support from the Proxim’s Customer support team.
- Page 13 Device Installation Figure 4-1 Weatherproofing RJ45 Connection Additional Weatherproofing Steps To add an additional layer of protection to the connectors against the environment, see Additional Weatherproofing Steps. Step 6: Assemble Mounting Hardware (When provided with the device) 1. Place the L-Shaped Mounting Bracket onto the bottom of the Device and align with the four mounting holes. 2.
- Page 14 Device Installation Figure 4-3 Pole Mounting (MP-1015 & MP-1025) 1. To pole mount the device, insert the two Hose Clamps through the hose clamp slits at the bottom of the Device. See Figure 5. 2. Place the device against the pole and tighten the hose clamps to the pole. Figure 4-4 Pole Mounting (MP-1035) Step 8: Plug in the Cables 1.
- Page 15 : The Surge Arrestor (Part Number 235-00001) is not provided with the Proxim’s Package Contents, it needs to be procured by the customer. To buy an additional Surge Protector, place an order separately with your distributor.
- Page 16 Device Installation Figure 4-6 Surge Protector : Use Outdoor-rated, UV protected, shielded Cat5e cable for the following: 3. Connect an RJ45 terminated cable between the indoor device and to the port on the surge protector at the building ingress. 4. Connect an RJ45 terminated cable between the surge protector and the outdoor device on the Ethernet Port. :Ensure to loop the cable before entering the premise to prevent water ingress.
- Page 17 Device Installation Figure 4-7 Ground the Device Step 12: Power ON the Device After connecting the PoE Injector and the device using straight-through CAT5e cable plug the power cord into a power outlet. There is no ON/OFF switch on the device. To power down the unit, unplug the RJ45 connector from the OUT / POE port on the PoE injector.
-
Page 18: Device Link Establishment
Device Link Establishment Antenna alignment is the process of physically aligning the antenna of the radio receiver and transmitter to establish a link between two point-to-point devices with an optimal throughput. The antenna alignment process is usually performed during the installation of the antennas. Refer to section 7.2.6.1 Antenna Alignment using CLI Commands. -
Page 19: Technical Specifications
Technical Specifications Device Models Model Part Description Number MP-1015-BS3-US 901-00359 Edge Multipoint 1015, Base Station, 100 Mbps, integrated antenna and RP-SMA - US PoE MP-1015-CPE-US 901-00360 Edge Multipoint 1015, Customer Premises Equipment, 100 Mbps, integrated antenna and RP-SMA - US PoE QB-1015-LNK-US 902-00941 Edge Quickbridge 1015, Link, 100 Mbps, integrated antenna and RP-SMA - US... -
Page 20: Accessories
Technical Specifications MP-1035-CPE-TH 901-00332 Edge Multipoint 1035, Customer Premise Equipment, 400 Mbps, integrated antenna and RP-SMA - TH PoE MP-1035-CPE-CN 901-00333 Edge MP 1035, Customer Premise Equipment, 400 Mbps, integrated antenna and RP-SMA - CN PoE MP-1035-CPE-JP 901-00358 Edge Multipoint 1035, Customer Premise Equipment, 400 Mbps, integrated antenna and RP-SMA - JP PoE QB-1035-LNK-WD 902-00907... -
Page 21: Ofdm Modulation Rates
Technical Specifications OFDM Modulation Rates Given below are the OFDM modulation rates for the Edge products: Data Rates (Mbps) Per Stream 20 MHz Channels 40 MHz Channels Modulation Coding Index Rate 800ns GI 400ns GI 800ns GI 400ns GI BPSK 13.5 QPSK 14.4... -
Page 22: Interfaces
Technical Specifications Interfaces Products Category Specification MP-1015-CPE Wired Ethernet Auto MDI-X, auto configuration fixed MP-1025-CPE speed/duplex configurations MP-1035-CPE One auto MDI-X RJ45 Gigabit Ethernet Port MP-1015-BS3 with PoE IN and Data MP-1025-BS3 QB-1015-LNK QB-1025-LNK QB-1035-LNK Transmit Power Specifications (5.150 - 5.925) GHz Tx Power* (dBm) VHT20 VHT40... -
Page 23: Receive Sensitivity (5.150 - 5.925) Ghz
Technical Specifications Receive Sensitivity (5.150 - 5.925) GHz Receive Sensitivity* (dBm) Products Stream Modulation Type Coding Rate (5.150 ~ 5.875) GHz VHT20 VHT40 BPSK Dual Stream MP-1015-CPE QPSK MP-1025-CPE QPSK MP-1035-CPE 16 QAM MP-1015-BS3 16 QAM MP-1025-BS3 64 QAM QB-1015-LNK 64 QAM QB-1025-LNK QB-1035-LNK... -
Page 24: Snr Information (5.150 - 5.925) Ghz
Technical Specifications SNR Information (5.150 - 5.925) GHz If DDRS is disabled, the user can configure the Data Rate values manually as per the reference table below. 5.150 - 5.925 GHz 20 MHz Modulation Index of Streams Full (GI = 800ns) Short (GI =400ns) Data Rate Min SNR... - Page 25 Technical Specifications 5.150 - 5.925 GHz 40 MHz 80 MHz Modulation Index Full (GI = 800ns) Short (GI = 400ns) Full (GI = 800ns) Short (GI = 400ns) Streams Data Data Data Data Rate Rate Rate Rate MCS0 BPSK 1/2 Single 13.5 29.3...
-
Page 26: Power Supply
Technical Specifications Power Supply Products Category Specification MP-1015-CPE Input Voltage Via RJ45 Ethernet interface supplying 56 V DC on Ethernet Port. MP-1025-CPE MP-1035-CPE Power consumption: 16 W typical, 18 W max (1015 & 1025) MP-1015-BS3 10 W typical, 12 W max (1035) MP-1025-BS3 QB-1015-LNK PoE Injector... -
Page 27: Environmental Specifications
Technical Specifications Environmental Specifications Products Operating Temperature Storage Temperature Humidity Wind Loading MP-1015-CPE -30º to 55º Celsius -50º to 70º Celsius 100% relative humidity 180 km/h MP-1025-CPE -22º to 131º Fahrenheit -58º to 158º Fahrenheit IP67 112.5 mph MP-1035-CPE MP-1015-BS3 MP-1025-BS3 QB-1015-LNK QB-1025-LNK... -
Page 28: Recommended Antennas
A Base Station and a Subscriber Station in a point-to-multipoint network. • • An End Point A and an End Point B in a point-to-point network. 7.2 Antennas Supported Proxim supports two types of directional antennas: • Flat Panel Antennas • Sector Antennas 7.2.1 Flat Panel Antennas... -
Page 29: Integrated Antenna Specifications
Recommended Antennas Figure 7-2 Sector Antenna Coverage 7.3 Integrated Antenna Specifications This section illustrates the technical specifications of the following: • MP-1015-CPE • MP-1025-CPE • MP-1035-CPE • MP-1025-BS3 • QB-1015-LNK (2 x QB-1015-EPR) • QB-1025-LNK (2 x QB-1025-EPR) • QB-1035-LNK (2 x QB-1035-EPR) Electrical Specification Products: MP-1015-CPE, MP-1025-CPE, MP-1035-CPE, MP-1015-BS3, MP-1025-BS3, QB-1015-LNK, QB-1025-LNK, QB-1035-LNK... - Page 30 Recommended Antennas Radio Patterns (H-Polar Port) Edge Multipoint and Quickbridge - Hardware Installation Guide...
- Page 31 Recommended Antennas Radio Patterns (V-Polar Port) Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 32: Recommended Antennas
This section illustrates the technical specifications of the following: • Sector Antenna Specifications • Panel Antenna Specifications : Ensure to use the same antenna specifications listed below, while using any of the non-proxim antennas. Edge Multipoint and Quickbridge - Hardware Installation Guide... -
Page 33: Sector Antenna Specifications
Recommended Antennas 7.5.1 Sector Antenna Specifications • 14 dBi Dual Polarized Sector Antenna • 15.5 dBi Dual Polarized Sector Antenna 7.5.1.1 14 dBi Dual Polarized Sector Antenna Electrical Specifications Frequency Range 4.9 GHz - 5.95 GHz Gain 14 dBi (min) VSWR 2:1 (max) 1.7: 1 (typ) Azimuth Beam Width... - Page 34 Recommended Antennas Antenna Patterns Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 35: Dbi Dual Polarized Sector Antenna
Recommended Antennas 7.5.1.2 15.5 dBi Dual Polarized Sector Antenna Electrical Specifications Frequency Range 4.9 GHz - 6.0 GHz Gain 15.5 dBi (typ) VSWR 2:1 (max) 1.7: 1 (typ) 3 dB Azimuth Beam Width 60° (typ) 3dB Elevation Beam width 8º (typ) Polarization Linear, Vertical and Horizontal Cross Polarization... - Page 36 Recommended Antennas Antenna Patterns Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 37: Panel Antenna Specifications
Recommended Antennas 7.5.2 Panel Antenna Specifications • 23 dBi Dual Polarized Panel Antenna • 29 dBi Dual Polarized Panel Antenna • 19 dBi Dual Polarized Panel Antenna 7.5.2.1 23 dBi Dual Polarized Panel Antenna Electrical Specifications Frequency Range 4.9 GHz - 5.875 GHz Gain 23.5 dBi V-Pol:24.5 ±... - Page 38 Recommended Antennas Antenna Patterns Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 39: Dbi Dual Polarized Panel Antenna
Recommended Antennas 7.5.2.2 29 dBi Dual Polarized Panel Antenna Electrical Specifications Frequency Range 4.9 - 5.15 GHz 5.15 - 5.875 GHz 5.875 - 6.1 GHz Gain 28.5±0.5 dBi 29±0.5 dBi 28.5±0.5 dBi • Vertical Pol. 28±0.5 dBi 28.5±0.5 dBi 28±1 dBi •... - Page 40 Recommended Antennas Antenna Patterns Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 41: Dbi Dual Polarized Panel Antenna
Recommended Antennas 7.5.2.3 19 dBi Dual Polarized Panel Antenna Electrical Specifications Frequency Range 4.9 - 6.425 GHz Gain 4.9 - 5.15 @ 4x18 dBi 5.15 - 6.425 @ 4x19 dBi VSWR, max. 1.7 :1 Polarization Quad Pole Vertical, Horizontal & Dual Slant (±45°) 3 dB Beam-Width-Azimuth, typ. - Page 42 Recommended Antennas Antenna Patterns Edge Multipoint and Quickbridge - Hardware Installation Guide...
- Page 43 Recommended Antennas Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 44: Antenna Installation
Antenna Installation 8.1 Safety Precautions Listed below are the safety precautions to be satisfied, prior to the outdoor antennas installation: Outdoor antennas and antenna cables (good conductors of electricity) should be installed properly to avoid the • transients or electrostatic discharges (that occur due to lightning during thunderstorm) from damaging your equipment and causing personal injury or death to the persons touching the exposed metal connectors of the equipment. -
Page 45: Required Materials
Antenna Installation 7. Ensure that the cabling of ethernet / power cables and the surge arrestor is proper. See Connecting the Surge Arrestor and Ethernet / Power cables. 8. Ensure that the antennas are grounded properly to the grounding system, satisfying the local electrical code requirements. -
Page 46: Determining The Optimal Antenna Placement
Antenna Installation 8.2.2 Determining the Optimal Antenna Placement To achieve the maximum throughput, the outdoor antenna must have clear line-of-sight with the antenna at the other end. The outdoor antennas are said to have a clear line-of-sight, when there are: •... -
Page 47: Mounting The Antenna
Report and Order FCC-14-30A1 are effective from June 2 , 2014. With the help of professional installation, all the Proxim devices can be configured to comply with the power requirements set in the rules. For an angle of elevation which is above 30 degrees, the maximum EIRP limit should be set to 125 mW (21 dBm). - Page 48 Azimuthal plane with respect to EIRP, but the Elevation plane has a limit specific to EIRP above 30 degrees as 21 dBm. To comply with this specification, Proxim products have an option to control the transmit power based on the installation tilt angle and the radiation pattern of the antenna.
- Page 49 Antenna Installation – The antenna gain for 0 = 0 is shown in the following figure: Figure 8-4 Antenna gain at (30- 0) = 30 – Transmit Power = EIRP - G - MIMO Gain (30- 0) = 21 - 5 = 16 dBm •...
- Page 50 Antenna Installation – Transmit Power = EIRP - G - MIMO Gain (30- 0) = 21 - 10 = 11 dBm Case 3: 0 = -15 (antenna tilted downward) • – The antenna gain for 0 = -15 is shown in the following figure: Figure 8-6 Antenna gain at (30- 0) = 45 –...
-
Page 51: Connecting The Cables
Antenna Installation 8.2.4 Connecting the Cables Once the outdoor antennas are properly mounted, the cable setup essential to complete the outdoor antenna installation is depicted in the following figure: Figure 8-7 Cable Setup The entire outdoor cabling setup requires the following cabling to be done: Connecting the Antenna Cable Connecting the Surge Arrestor and Ethernet / Power cables Grounding the System... -
Page 52: Connecting The Surge Arrestor And Ethernet / Power Cables
Antenna Installation 5. If required, adjust the direction of the antenna. 6. Tighten the nuts of the antenna to lock the antenna into its position. : Avoid over-tightening of the connector, nuts and screws that are used to mount the antenna, to protect the antenna and device from getting damaged. -
Page 53: Grounding The System
Antenna Installation approved lightening surge protector near the device is recommended. To buy an additional Surge Protector (Part Number: 235-00001), place an order separately with your distributor. : The surge arrestor and the antenna mast must be connected to the same grounding system, by using the shortest cable possible, as prescribed by local electrical codes. - Page 54 Antenna Installation Step 1: Wrap vinyl tape in a half-lapped fashion, from the weatherproof connector end and continue wrapping down 3 inches onto the CAT5e cable. a. Weatherproofing at the device end: b. Weatherproofing at the antenna end: Step 2: Wrap a second layer of vinyl tape in the reverse direction over the first layer of tape. a.
- Page 55 Antenna Installation Step 3: Now, wrap a third layer of vinyl tape over the other two layers but with the adhesive side up as this provides a sticky surface for the next layer. a. Weatherproofing antenna connectors on the device: b.
-
Page 56: Aligning The Antenna
Antenna Installation a. Weatherproofing antenna connectors on the device: b. Weatherproofing antenna cable: Step 6: Place a small zip tie over the last wrap of tape to prevent it from unwrapping over time. The figure below depicts the complete weatherproofing of the RF connection. 8.2.6 Aligning the Antenna Antenna alignment is the process of physically aligning the antenna of the radio receiver and transmitter to establish a link with a better throughput. -
Page 57: Antenna Alignment Using Cli Commands
Antenna Installation : Applicable only to the devices with the back-haul feature (i.e., devices with 5 GHz Antennas). 8.2.6.1 Antenna Alignment using CLI Commands To enable the antenna alignment display from the CLI prompt, enter the following commands: aad enable local: Enables display of the local signal, noise and SNR. •... -
Page 58: Measuring Signal Performance
Measuring Signal Performance 9.1 Introduction The performance of a microwave link (wireless link established between two outdoor antennas) is closely related to the following factors: Range • • Fresnel Zone • Clearance Factor Calculating the above factors help you align the antennas properly and achieve a better throughput. 9.2 Determining the Range Range is the maximum distance a microwave link travels and is based on the: Type of the outdoor antenna equipment (Outdoor antennas differ in technical specifications). -
Page 59: Fresnel Zone Calculation
Measuring Signal Performance • Marginal communications quality in late fall (with no leaves on the trees along the signal path) might fail in the summer (with leaves on the trees along the signal path). In winter, a wireless link can fail when the antenna is exposed to ice buildup or when the antenna elements are •... -
Page 60: Clearance Factor
Measuring Signal Performance The path difference is the required clearance of the antenna beam from obstacles in its path to avoid loss of radio signal. Signals reflected from any even-numbered Fresnel Zone result in signal cancellation while the odd-numbered Fresnel Zones add to the direct path signal. -
Page 61: Calculations
: Practically, it is impossible to achieve the maximum range due to the interference from the other radio products. Proxim recommends you to maintain at least 60-70% of the first Fresnel Zone free. If the clearance is lower than this percentage, then the link budget and acquired fade margin are affected. - Page 62 – D is the distance of the path in miles. • This formula is available on a calculation sheet provided by Proxim to generate an estimate of link distance and reliability. • The path loss must be smaller than the link budget minus the minimum required fade margin. The maximum ranges cause the path loss plus the fade margin to be the same as the link budget.
- Page 63 Measuring Signal Performance Procedure 1. Start with the transmit power and the number of the channel to be used in dBm. Subtract the total loss of all transmission elements between the antenna and the radio on one side of the link (dB). 2.
- Page 64 For details, we recommend you to refer the Max EIRP values listed under the Wireless Interface properties, in the Edge - Hardware Installation Guide. The figure below shows the Proxim Link Calculator, available at http://support.proxim.com. Refer to Link Calculator - User Guide to understand: How to install the Link calculator •...
- Page 65 Measuring Signal Performance FCC United States 5.8GHz band power limit for band edge frequencies Edge Multipoint and Quickbridge - Hardware Installation Guide...
-
Page 66: A Lightning Protection
The surge arrestor (sometimes referred to as a lightning protector) can protect your sensitive electronic equipment from high-voltage surges caused by discharges and transients at the PoE. Proxim Wireless offers superior lightning and surge protection for Edge 10xx Series products. Contact your reseller or distributor for more information. -
Page 67: B Abbreviations
Abbreviations Abbreviations American Wire Gauge Base Station Unit Command Line Interface Customer Premises Equipment Direct Current Electrostatic Discharge Frame Check Sequence Light Emitting Diode MIMO Multiple-input and Multiple-output MTBF Mean Time Between Failures OFDM Orthogonal frequency-division multiplexing Personal Computer Power Over Ethernet PTMP Point-to-multipoint Point-to-point... -
Page 68: C Warranty And Technical Support
Obtaining Technical Service and Support If you are having trouble using the Proxim product, please read this manual and the additional documentation provided with your product. If you require additional support to resolve your issue, please be ready to provide the following information before you contact Proxim’s Technical Services team:... -
Page 69: Additional Information On Servpak Options
Business Hours: Tier 1 support: 24x7 live response. Tier 3 support: 8 a.m. to 5 p.m. M-F PST (UTC/GMT -7 hrs) ServPak Support To provide even greater investment protection, Proxim Wireless offers a cost-effective support program called ServPak. ServPak is a program of enhanced service support options that can be purchased as a bundle or individually, tailored to meet your specific needs. - Page 70 Basic Technical Support Customers who purchase this service can be rest assured that their call will be answered by Proxim’s Tier 1 technical support and a case opened immediately to document the problem and provide initial troubleshooting to identify the solution and resolve the incident in a timely manner.
-
Page 71: D Safety & Regulatory Information
Safety & Regulatory Information For Safety & Regulatory Information, please refer Safety and Regulatory guide for Edge MP-10x5 Series. To download the Safety and Regulatory Guide, visit http://support.proxim.com. Edge Multipoint and Quickbridge - Hardware Installation Guide...
