Proxim MeshMAX 3500W Specifications

MeshMAX™ Series
Product 3500WM, 3500W, 5054WM, 5054W
Description Industry's fi rst convergence of
WiMAX, Wi-Fi ® Mesh and Wi-Fi
Applications • Network operator can deliver bundle
of IPTV, VoIP and Internet access to
subscribers
• Secure and reliable backhaul of Wi-Fi
Mesh traffi c
• Security and surveillance
Environments • Municipal, rural and service
provider broadband networks
• Enterprise campus networks
Key Features • Tri-radio design provides WiMAX
backhaul, Wi-Fi Mesh link and Wi-Fi
access in one device
• Simplifi es network architecture, de-
ployment and management
• Signifi cantly reduces TCO with low-
est deployment cost per square mile
SPECIFICATIONS
Frequency Band • 3.5 GHz or 5.15-5.85 GHz (WiMAX link)
• 5.15-5.85 GHz (Mesh link)
• 2.4 GHz or 5.15-5.85 GHz (Wi-Fi access)
Wireless Protocol • 802.16-2004 or WORP (WiMAX)
• 802.11a (Wi-Fi and Mesh)
• 802.11b/g (Wi-Fi)
Data Rate • 25.4 Mbps (3.5 GHz)
• 54 Mbps (5.15-5.85 GHz and 2.4 GHz)
QoS 802.16d QoS (WiMAX); Draft 802.11e,
802.1p, 802.1q (Wi-Fi Mesh)
Security • AES (WiMAX)
• 802.11i, AES, TKIP (Wi-Fi Mesh)
Form Factors ODU tri-radio device, 3 x
Type-N connectors
For detailed technical specifi cations, please visit http://www.proxim.com/products/landing_wimax.html
© 2007 Proxim Wireless Corporation. All rights reserved. Proxim and the Proxim logo are registered trademarks and MeshMAX and Tsunami are trademarks of Proxim Wireless Corporation. Any other trademarks mentioned
herein are property of their respective owners. Specifi cations are subject to change without notice. Availability subject to local regulations. Performance results may vary due to environment and implementation.
ATAG_0407_WIMAX_A4
Tsunami™ MP.16 Series
MP.16 3500 MP.11 4954-R
WiMAX Forum Certifi ed™ products Capabilities of fi xed and mobile
for 3.5 GHz frequency band WiMAX for public safety
• Broadband last-mile access for met- • Transmission of critical data
ropolitan and rural areas and video from emergency fi rst re-
• Voice, video and data transmission sponder vehicles
with optimal economics • Real-time delivery of IP-surveillance
• Security and surveillance video from security cameras
• Service provider and municipal • Public safety broadband networks
broadband networks • Broadband access for emergency fi rst
• Security and surveillance responders
• Security and surveillance
• Product complies with IEEE 802.16 • WiMAX capabilities for 4.9 GHz fre-
- 2004 standard quency band for public safety
• WiMAX QoS for voice, voice, data • WiMAX QoS for voice, data and
• All-in-one, outdoor base station delivers video
scalable solution by allowing single sec- • Fast handoffs for mobility up to 200
tor deployments to grow into multi-sec- km/hr
tor deployments
3.40 - 3.60 GHz 4.94-4.99 GHz
802.16-2004 Wireless Outdoor Routing Protocol
(WORP; proprietary)
25.4 Mbps 54 Mbps
802.16d QoS (WiMAX) 802.16d QoS (WiMAX)
• AES • AES
• Radius base authentication of sub- • Proprietary nature of RF protocol
scribers based on MAC address • Packet fi ltering, Intracell blocking
• Base: ODU, N-connector • Base: ODU, N-connector
• Subscriber station: ODU, • Subscriber station: ODU,
N-connector or Integrated 21 dBi N-connector or Integrated 21 dBi
Antenna Antenna
Proxim Wireless At-a-Glance
WiMAX Product Portfolio
Tsunami™ MP.11 Series
MP.11 2454-R/5054-R MP.11 5012
Capabilities of fi xed and mobile Economical subscribers ideal for
WiMAX for license-free frequencies large scale deployments
• Broadband last-mile access for • Broadband last-mile access for met-
metropolitan and rural areas ropolitan and rural areas
• Voice, video and data transmission • Voice, video and data transmission
with optimal economics with optimal economics
• Security and surveillance
• Service provider and municipal • Service provider and municipal
broadband networks broadband networks
• Broadband access for ground and • Broadband access for residential
water transportation market
• Security and surveillance
• WiMAX capabilities for license-free • Aggressive ROI and fast payback for
frequency bands network providers
• WiMAX QoS for voice, data • Compatible with existing MP.11 5054
and video products
• Fast handoffs for mobility up to 200 • Throughput comparable to or better
km/hr than cable/DSL
• 2.4 GHz (2454-R) • 5.15-5.35 GHz,
• 5.25-5.35 GHz (5054-R) • 5.47-5.725 GHz and
• 5.4-5.7 GHz (5054-R) • 5.725-5.850 GHz
• 5.725-5.850 GHz (5054-R)
Wireless Outdoor Routing Protocol Wireless Outdoor Routing Protocol
(WORP; proprietary) (WORP; proprietary)
54 Mbps 12 Mbps
802.16d QoS (WiMAX) 802.16d QoS (WiMAX)
• AES • AES
• Proprietary nature of RF protocol • Proprietary nature of RF protocol
• Packet fi ltering, Intracell blocking • Packet fi ltering, Intracell blocking
• Base: ODU, N-connector • Indoor Subscriber: Bundled with 15
• Subscriber station: ODU, N-connector or dBi Window Antenna
Integrated 18 or 23 dBi Antenna • Outdoor Subscriber: Integrated
• Indoor Subscriber 18 dBi Antenna
www.proxim.com
