Quick Install Guide
Tsunami MP.11
Model 5012-SUR
Version 3.0.1
Part Number: 73226 (CD version)
73227 (Print version)

Advertisement

Table of Contents
loading

Summary of Contents for Proxim TSUNAMI MP.11 5012-SUR

  • Page 1 Quick Install Guide Tsunami MP.11 Model 5012-SUR Version 3.0.1 Part Number: 73226 (CD version) 73227 (Print version)
  • Page 2 Proxim Wireless Corporation. trademarks Tsunami, Proxim, and the Proxim logo are trademarks of Proxim Wireless Corporation. All other trademarks mentioned herein are the property of their respective owners.
  • Page 3: Table Of Contents

    coNteNts Introduction..4 Key Features ...4 Package Contents ...5 Hardware.and.Software.Installation..6 Step 1: Choose a location ...7 Step 2: Attach cables ...8 Step 3: Mount Unit to Pole ... 10 Step 4: View LEDs/Adjust Mounting ... 12 Step 5: Close Cable Compartment ...
  • Page 4: Introduction

    R, 5054-R-LR, and 2454-R Base Station and Subscriber Units for outdoor installation. The 5012-SUR is fully compatible with Base Station models 5054, 5054-R, and 5054-R-LR. Key Features Some of the key features of the Tsunami MP.11 5012-SUR are: ▪ The use of a highly optimized protocol for outdoor situations ▪...
  • Page 5: Package Contents

    PacKaGe coNteNts Each Tsunami 5012-SUR shipment includes the items listed in the following table. Verify that you have received all parts of the shipment. Note:.. Cables are not provided with the unit. 5012-SUR unit Band clamps (2) Installation CD All rights reserved Page ...
  • Page 6: Hardware.and.software.installation

    Dynamic Frequency Selection (DFS) and Transmit Power Control (TPC). ▪ Equipment is to be used with and powered by an 802.3af-compliant power injector (purchased separately). Page 6 IMPORTANT! IMPORTANT! Copyright © 2006 Proxim Wireless...
  • Page 7: Step 1: Choose A Location

    The units are designed to mount directly to a 1” - 1.5” pole (not included) using the supplied band clamps. An optional universal pole mounting kit is also available from Proxim (P/N 1087-UMK); this kit is designed to mount directly to a flat surface such as a roof, wall, or under an eave.
  • Page 8: Step 2: Attach Cables

    Connect the other end of the Ethernet cable to the Data and Power Out port of the DC Injector. Note: You must use an 802.3af-compliant power injector, such as the Proxim 1- Port Power Injector (P/N 4301-xx). Connect one end of a second Ethernet cable (not supplied) to the Data In...
  • Page 9 a switch, hub, or patch panel. ▪ Use a cross-over Ethernet cable or adapter if you are connecting the unit to a single computer or most router ports. All rights reserved Page ...
  • Page 10: Step 3: Mount Unit To Pole

    Note: Do not fully tighten band clamps; you must first ensure a functional link to the BSU (see Step 4: View LEDs/Adjust Mounting). Page 10 Copyright © 2006 Proxim Wireless...
  • Page 11 Do not fully tighten band clamps; you must first ensure a functional link to the BSU (Step 4: View LEDs/Adjust Mounting). The mounted unit, using the optional Proxim universal pole mounting kit (P/N 1087-UMK), is shown below. All rights reserved...
  • Page 12: Step 4: View Leds/Adjust Mounting

    BSU. When the Power LED is solid green, the link is correctly established. Page 12 Power Wireless.Link Solid green Blinking green Ethernet.Link Solid green Blinking green Copyright © 2006 Proxim Wireless...
  • Page 13: Step 5: Close Cable Compartment

    step 5: close cable compartment Ensure that the Ethernet cable is properly routed and exiting the unit through the notch at the bottom of the cable compartment. Position the cable cover so that the notch in the cover fits over the Ethernet cable (not pictured) and the large tabs on the cover are aligned below the holes in the unit.
  • Page 14 The assembly with the cable cover attached is shown below. Page 1 Copyright © 2006 Proxim Wireless...
  • Page 15: Step 6: Tighten Band Clamps

    12 inches of the unit. Continue to secure cable with cable ties at 3-foot intervals. The final assembly, using the optional Proxim universal pole mounting kit (P/N 1087-UMK), is shown below.
  • Page 16: Step 7: Install Documentation And Software

    Scan Tool program Documentation (in Docs folder): See list above Help files (in Help folder; click on index.htm to access) Extras folder containing TFTP Server and Scan Tool program MIBs (in MIBs folder) Page 16 Copyright © 2006 Proxim Wireless...
  • Page 17: Initialization

    CD), you can find out the current IP address of the unit and, if necessary, change it so that is appropriate for your network. ScanTool lets you find the IP address of a Tsunami MP.11 5012-SUR by referencing the MAC address in a Scan List, or to assign an IP address if the correct one has not been assigned.
  • Page 18 IP.Address.Type. The unit will request its IP address from a DHCP server on your network. Enter the Read/Write.Password (the default value is public) and click OK to confirm your changes. The respective unit reboots to make the changes effective. Page 1 Copyright © 2006 Proxim Wireless...
  • Page 19: Accessing The Web Browser

    accessing the web Browser To access the unit with a Web browser: Start your Web browser and enter the IP address of the unit in the Address box. The Web address should appear as http://<ip.address> (for example, http://10.0.0.1). A login window is displayed. A login window is displayed.
  • Page 20: Accessing The Command Line Interface

    You still need the CLI password of the unit. Proxim recommends you power off the radio and the computer before connecting or disconnecting the serial cable.
  • Page 21: Default.settings

    deFault settINGs Setting Mode of Operation Routing IP Address Assignment IP Address Subnet Mask Default Router IP Address Default TTL RIPv2 (if in routing Mode) Base Station System Name Network Name Frequency Channel Transmit Power Control Data Rate Registration Timeout Network Secret Turbo Mode Channel Bandwidth...
  • Page 22 SU: Transparent mode when BSU is in Transparent mode; Trunk mode when BSU is in Trunk mode. BSU: N/A; SU: 1 BSU: N/A; SU: 0 BSU: -1; SU: -1 BSU: 0; SU: 0 BSU: N/A; SU: 1 Copyright © 2006 Proxim Wireless...
  • Page 23: Technical.services.and.support

    If you are having trouble utilizing your Proxim product, please review the Tsunami MP.11 5012-SUR Installation and Management Guide and the additional documentation provided with your product. If you require additional support, please refer to the “Technical Services and Support”...
