Parker 4 Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B
bolt & 50mm screw 30mm screw
locking nut x8
x44
F G
14mm screw 18mm screw
x36 x8
F K
14mm screw 25mm screw
x2 x5
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
C D
E1
50mm screw
x8 x16
H I J
bracket handle dowel
x8 x4 x8
Hardware Supplied
L M
wall plug wall strap
x2 x2
E
E3
E4
E2
rails
x8
WARNING: Any furniture that is not anchored to a wall has the
potential to tip over in certain circumstances, ie. if a child attempts
Wall Strap
to climb on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The
fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from
those supplied.
