USE AND CARE GUIDE
ROYCE FILE CABINET
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-998-7021
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this Royce file cabinet. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection ROYCE SK19051Er1-SB-1
Summary of Contents for Home Decorators Collection ROYCE SK19051Er1-SB-1
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this Royce file cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Hardware Included ..............3 Table of Contents ............2 Safety Information ............2 Pre-assembly (continued) ..........4 Warranty ................. 2 Package Contents ..............4 3 Year Warranty ...............2 Assembly ............... 5 ... -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Top panel Left side panel Right side panel Bottom panel Crossbar Back panel Drawer front panel Top drawer left side panel Top drawer right side panel Drawer back panel Drawer bottom panel Support bar Bottom drawer left side panel Bottom drawer right side panel Metal... -
Page 5: Assembly
Assembly Attaching the back panel to the left side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (B). c) Join panel (F) to the panel (B) with dowel (AA). □ b) Insert lock (CC) into panel (F). □... - Page 6 Assembly (continued) Attaching the back panel to the right side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (C). c) Join panel (F) to the panel (C) with dowel (AA). □ □ b) Insert lock (CC) into panel (F). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 7 Assembly (continued) Attaching the crossbar □ □ a) Insert lock (CC) into bar (E). c) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □ b) Insert dowel (AA) into panel (F) first. Join bar (E) to the panels (B) and (C) with dowel (AA). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 8 Assembly (continued) Attaching the bottom panel □ □ a) Install dowel (AA) and bolt (BB) into panel (D). c) Join panel (D) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panels (B),(C) and (F). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 9 Assembly (continued) □ Attaching the top panel c) Join panel (A) in the assembled body with dowel (AA). □ a) Install bolt (BB) into panel (A). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. b) Insert lock (CC) into panels (B),(C) and (F). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 10 Assembly (continued) □ d) Tighten panel (J) to the assembled body Assembling the drawer with screw (DD) and dowel (AA). □ a) Install dowel (AA) and bolt (BB) into panel (G). □ b) Insert lock (CC) into support bar (L). □...
- Page 11 Assembly (continued) □ d) Tighten panel (J) to the assembled body Assembling the drawer with screw (DD) and dowel (AA). □ a) Install dowel (AA) and bolt (BB) into panel (G). □ b) Insert lock (CC) into support bar (L). □...
- Page 12 Assembly (continued) Inserting the drawer □ Insert the drawer into the assembled body as shown. NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body. SAFETY RELEASE TAB NOTE: When removing the drawer, tip-up the safety release tab to remove the drawer from the body.
- Page 13 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
