Item # 1004237621
Model # SK19239Dr1-E
Item # 1004237622
Model # SK19239Dr1-S
USE AND CARE GUIDE
BUFFET WITH GLASS DOOR
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-998-7021
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this buffet with glass door. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection SK19239Dr1-E
Summary of Contents for Home Decorators Collection SK19239Dr1-E
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this buffet with glass door. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Hardware Included ..............3 Table of Contents ............2 Safety Information ............2 Pre-assembly (continued) ..........4 Warranty ................. 2 Package Contents ..............4 3 Year Warranty ...............2 Assembly ............... 5 ... -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Top panel Side panel Partition Adjustable shelf Bottom panel Side foot Middle foot Left door Right door Back panel... -
Page 5: Assembly
Assembly Attaching the foot to bottom panel □ a) Attach side foot (F) to the panel (E) with washers (FF) and (GG), and bolt (EE). Turn and tighten bolt (EE) with wrench (HH). □ b) Tighten middle foot (G) to the panel (E) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance. - Page 6 Assembly (continued) Attaching the partition and side panel to bottom panel □ a) Install dowel (AA) and bolt (BB) into panel (E). c) Join partition (C) and panel (B) to the panel (E) with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
- Page 7 Assembly (continued) Attaching the top panel □ □ a) Install dowel (AA) and bolt (BB) into panel (A). c) Join panel (A) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into partition (C) and panel (B). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 8 Assembly (continued) Assembling the back panel □ a) Install wire plug (KK) into panel (J) as shown. □ b) Tighten panel (J) to the assembled body with screws (II) as shown.
- Page 9 Assembly (continued) Assembling the adjustable shelf □ Insert shelf supports (JJ) in desired positions and place shelf (D) on the supports. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 10 Assembly (continued) Attaching the door □ a) Attach door (H) to the assembled body by inserting wheels on the bottom of door (H) into the inside track on the top of bottom panel (E) as shown, find the pin on top of door (H) pressing the button down to make flat. □...
- Page 11 Assembly (continued) Attaching the door □ Attach door (I) to the assembled body by using same methods as in step 6. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 12 Assembly (continued) Attaching the door □ Attach the other door (I) to the assembled body by using same methods as in step 6.
- Page 13 Assembly (continued) Attaching the door □ Attach the other door (H) to the assembled body by using same methods as in step 6. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 14 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown.
- Page 15 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-998-7021 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
