We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this 2-door cabinet console. We
strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
USE AND CARE GUIDE
2-DOOR CABINET CONSOLE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
HOMEDEPOT.COM/HOMEDECORATORS
improvement needs. Thank you for choosing Home Decorators Collection!
Item #1004459930
Model #SK19337r2-C-1
Item #1004459928
Model #SK19337r2-C-2
1-800-998-7021
THANK YOU
Item #1004459940
Model #SK19337r2-V-1
Item #1004459939
Model #SK19337r2-V-2
Model #SK19337r2-V-2
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection SK19337r2-C-1
Summary of Contents for Home Decorators Collection SK19337r2-C-1
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this 2-door cabinet console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Hardware Included ..............3 Table of Contents ............2 Safety Information ............2 Pre-assembly (continued) ..........4 Warranty ................. 2 Package Contents ..............4 3 Year Warranty ...............2 Assembly ............... 5 ... -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Top panel Left side panel Right side panel Left partition Right partition Adjustable shelf Crossbar Fixed panel Bottom panel Short crossbar Front crossbar Back panel Left door Right door Drawer front panel Drawer left side panel Drawer right side panel Drawer back panel Drawer botton panel... -
Page 5: Assembly
Assembly Attaching the crossbar to the left partition □ □ a) Install dowel (AA) and bolt (BB) into partition (D). c) Join bar (G) to the partition (D) with dowel (AA). □ b) Insert lock (CC) into bar (G). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled hole. - Page 6 Assembly (continued) Attaching the right partition □ □ a) Install dowel (AA) and bolt (BB) into partition (E). c) Join partition (E) to the bar(G) with dowel (AA). □ □ b) Insert lock (CC) into bar (G). d) Tighten bolt (BB) with lock (CC) in the pre-drilled hole.
- Page 7 Assembly (continued) Attaching the fixed panel □ c) Join partitions (D) and (E) to the panel (H) □ a) Install dowel (AA) and bolt (BB) into panel (H). with dowel (AA). □ b) Insert lock (CC) into partitions (D) and (E). □...
- Page 8 Assembly (continued) Attaching the short crossbar and left side panel □ □ a) Join bar (J) to the panel (B) with dowel (AA). d) Join panel (B) to the assembled body and panel (I) with dowel (AA). □ b) Install dowel (AA) and bolt (BB) into panel (B). Tighten bar (J) with screw (HH).
- Page 9 Assembly (continued) Attaching the front crossbar, short □ d) Insert lock (CC) into panels (H) and (I). crossbar and right side panel □ a) Attach magnet (JJ) to bar (K) with screw (KK). □ e) Join panel (C) and bar (K) to the assembled body □...
- Page 10 Assembly (continued) Attaching the top panel □ □ a) Install dowel (AA) and bolt (BB) into panel (A). c) Join panel (A) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled □...
- Page 11 Assembly (continued) Attaching the back panel □ a) Install wire plug (MM) into panel (L) as shown. □ b) Tighten panel (L) to the assembled body with screws (KK) as shown. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-998-7021 for further assistance.
- Page 12 Assembly (continued) Attaching the adjustable shelf □ Insert shelf supports (LL) in desired positions and place shelf (F) on the supports.
- Page 13 Assembly (continued) Attaching the door □ a) Attach doors (M) and (N) to the assembled body with screw (II) as shown. NOTE: Metal plate needs to be to the top. □ b) Tighten knob (EE) to doors (M) and (N) with bolt (FF). NOTE: A helper who can hold the door in position makes the door installation easier.
- Page 14 Assembly (continued) Assembling the drawer □ □ a) Tighten panels (P) and (Q) to panel (O) with screw (GG). c) Tighten panel (R) to the assembled body with screw (GG). □ □ d) Tighten knob (EE) to panel (O) with bolt (FF). b) Slide panel (S) into the grooves on panels (P) and (Q).
- Page 15 Assembly (continued) Inserting the drawer □ Insert the drawer into the assembled body as shown. NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body. SAFETY RELEASE TAB NOTE: When removing the drawer, tip-up the safety release tab to remove the drawer from the body.
- Page 16 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown.
- Page 17 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-998-7021 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
