Summary of Contents for Clarke AP14GF
- Page 1 SPRAY GUN MODEL NO: AP14GF PART NO: 3082120 OPERATION & MAINTENANCE INSTRUCTIONS DL0821...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Spray Gun. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: General Safety Rules
GENERAL SAFETY RULES Before using this equipment it is in your own interest to read and pay attention to the following safety rules. 1. Keep the work area clean. Cluttered areas invite injuries. Keep work area well lit. 2. Keep children away. Children must never be allowed in the work area. 3. - Page 4 Only use the product for the purpose for which it is intended. 10. When replacing parts, only use those supplied by Clarke International as per the parts list. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 5: Product Overview
PRODUCT OVERVIEW DESCRIPTION DESCRIPTION Locking Ring Paint Container Side Wings Paint Flow Adjustment Knob Air Cap Needle Spray Pattern Adjustment Knob Air Nozzle Airline Connection Trigger Cleaning Brush Airflow Adjustment Knob Spanner Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 6: Specification
SPECIFICATION Container Volume 600 ml Air Inlet Connection 1/4” BSP Minimum Compressor Size 3 HP Typical Operating Pressure 30-43 psi Maximum Operating Pressure 43 psi Paint Delivery 190-250 ml/min Weight 767 g Depth x Width x Height 170 x 100 x 330m Air Consumption 390 l/min Nozzle Size... -
Page 7: Operation
OPERATION The AP14GF spray gun is fed with paint by gravity from the paint container. The air-flow through the air cap draws paint into the nozzle assembly, where it is atomised and sprayed forward. The AP14GF spray gun is supplied with one nozzle size, (1.4 mm). Ensure your spray gun is matched to the capacity of your compressor. -
Page 8: Paint Thinning
PAINT THINNING Paint thinning is particularly important when spraying. Many paints are supplied ready for brush application and need to be sufficiently diluted for spraying purposes. Always follow the paint manufacturers instructions. If in doubt, always consult the paint manufacturer. A Viscosity Cup (not supplied), will assist in determining the correct thickness of the paint. -
Page 9: Adjustments Of The Spray Gun
ADJUSTMENTS OF THE SPRAY GUN ADJUSTING THE PAINT FLOW 1. Set the Paint Flow Adjustment knob (8) according to the paint in use and the spray pattern required. (anticlockwise to increase, clockwise to reduce flow). ADJUSTING THE SPRAY PATTERN 1. Turn the Pattern Adjustment knob (9) anticlockwise to give a fan shaped spray pattern, turning clockwise to give a circular spray pattern. - Page 10 To obtain the best results, keep your spray gun level and parallel to the surface at all times. Keep the nozzle 23 - 30 cm from the surface and spray evenly from side to side or up and down. Use your arm to control the spray gun, not your wrist.
-
Page 11: Troubleshooting
• The material deposited should always be even and wet. Lap each stroke over the preceding stroke to obtain a uniform finish. • To ensure the edges are covered, start spraying just to the side of the area being sprayed and do not stop until the spray has gone past the opposite edge. -
Page 12: Maintenance
6. Finally, empty the spray gun and dry all components thoroughly. Store in a clean, dry place. AIRLINE ACCESSORIES AND EQUIPMENT 1. An extensive range of airline equipment is available from your Clarke dealer including hoses, retractable hose reels, filter/regulators, in-line regulators, pressure gauges, spray gun cleaning kit, respiratory masks and safety goggles. -
Page 13: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts List
PARTS LIST DESCRIPTION DESCRIPTION Gun Body 28 Fulcrum Pin Needle Sealing Spring 29 Trigger Gasket Gasket 3 30 Pattern Adjustment Gasket Needle Sealing Gasket 31 Pattern Adjustment Seat Needle Sealing Nut 32 Pattern Adjustment Stem Airflow Separating Ring 33 Pattern Adjustment Sealing Ring Sealing Ring 34 Pattern Adjusting Knob Nozzle Seat... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
