- Page 1 0700 SPRAY GUN Model PS1 Part No.5080815 OPERATING & MAINTENANCE INSTRUCTIONS...
-
Page 2: Specifications
25-45 litres of latex. Replacement valves are available from your dealer or the Clarke International Parts Department. For Spare Parts and Service, please contact your nearest dealer, or Clarke International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS &... -
Page 3: For Your Own Safety
Thank you for purchasing this Clarke PS1 Spray Gun. Before attempting to use this appliance, please read this instruction manual thoroughly, and carefully follow all directions given. This is for your own safety and that of others around you, and to help you achieve long and trouble free service from your spray gun. -
Page 4: Parts Identification
Parts Identification... -
Page 5: Using The Spray Gun
Using the Spray Gun The PS1 Spray Gun is fed with paint by a siphon (or suction) effect from the paint cannister. The air flow through the air cap draws paint up the feed tube, into the nozzle assembly, where it is atomised and sprayed forward. -
Page 6: Air Supply
Air Supply For best results, the air supply to the spray gun must be clean and dry, with no oil or water contamination. Follow the air compressor manufacturer is guidelines on installation and operation to ensure that your air supply is as clean as possible. The compressed air supply line to the spray gun must be fitted with an oil and water extractor and a suitable pressure regulator. -
Page 7: Spraying Technique
Spraying Technique When spraying, the Spray Gun should be held square to the surface being painted, at a distance of 8 to 12 inches (20 - 30cm) from the surface. Keep the gun parallel to the surface being sprayed, starting the stroke before pulling the trigger, and releasing the trigger before ending the stroke. -
Page 8: Maintenance
Maintenance WARNING! Disconnect the spray gun from the air supply, and relieve any pressure in the gun and hose, before any disassembly. It is essential that the spray gun is kept clean. Dried paint in the nozzle assembly or airways will stop the gun from working. For the gun to perform at its best it must be cleaned and lubricated after every use. -
Page 9: Parts List And Diagram
Parts List and Diagram No. Description Part No. Description Part No. Plastic Ring ANBE089444 Nozzle Assy 1.2mm ANBH089519 Suction Pipe ANBT089445 Retaining Ring ANBI088134 Canister ANBL088019 Needle Valve Support ANBS088227 Packing ANBD089684 Packing Seal ANBD088174 Body ANBH088769 Needle Guide ANBS089478 Fluid Control Adj.
