- Page 1 Product User Guide RFCurrent2000A RFCurrent2000A Wireless Current Data Logger To view the full MadgeTech product line, visit our website at www.madgetech.com.
-
Page 2: Table Of Contents
Installation Guide ........... 9 Mounting Instruction ........10 Channel Programming ......... 11 Deployment & Activation ......12 General Specifications ........12 Compliance Information ........ 13 Troubleshooting Tips .... Back Cover To view the full MadgeTech product line, visit our website at www.madgetech.com. -
Page 3: Quick Start Steps
“Wireless: OFF”. If wireless mode is on, press and hold the Wireless button on the device for 5 seconds. The RFCurrent2000A comes with a USB cable. Plug one end of the cable into an available USB port on the PC and plug the opposite end of the cable into the communication port on the RFCurrent2000A. -
Page 4: Product Overview
The engineering unit is available for display on the LCD screen as well as in the software. The RFCurrent2000A is available in 20mA, 160mA or a 3A measurement range. -
Page 5: Additional Features & Operation
5. Click OK. The OK button will be disabled if the Rule name box is empty. Changing the Alarm Settings of a Device 1. In the Connected devices panel, select the RFCurrent2000A device. 2. Click the Properties button under the device tab at the top of the software, and select the Alarm tab in the Properties window. -
Page 6: Mounting Instructions
Product User Guide Mounting Instructions The base provided with the RFCurrent2000A can be used in two ways. • The bottom of the logger snaps in place to use and mount the unit on a table top or horizontal surface. • The base can also securely snap to the backside of the logger for wall mounting if desired (as shown below). -
Page 7: Product Maintenance
Recalibration only $40.00 RMA Instructions To send a device back in to MadgeTech, follow the instructions below to create an RMA (Return Merchandise Authorization) on the MadgeTech website: 1. Visit www.madgetech.com, under the Services tab select RMA Process. 2. When the web page opens, please sign in. If this is the first time, select Click here to register an account and create one. -
Page 8: General Specifications
USB to mini USB, 250,000 baud for standalone operation or RFC1000/ Computer Interface RFC1000-CE/RFC1000-IP69K required for wireless operation Software XP SP3/Vista/Windows 7/Windows 8 (MadgeTech 4 only) Operating -20 °C to +60 °C (-4 °F to +140 °F) 0 %RH to 95 %RH non-condensing Environment •... - Page 9 WARNING: BATTERY MAY LEAK, FLAME OR EXPLODE IF DISASSEMBLED, SHORTED, CHARGED, CONNECTED TOGETHER, MIXED WITH USED OR OTHER BATTERIES, AND/OR EXPOSED TO FIRE/HIGH TEMPERATURE. DISCARD USED BATTERY PROMPTLY, KEEP OUT OF REACH OF CHILDREN. Specifications subject to change. See MadgeTech’s terms and conditions at www.madgetech.com...
- Page 10 Product User Guide RFC1000 Wireless Transceiver Other models available: RFC1000-CE - Approved for European markets RFC1000-IP69K - Splash Proof for harsh environments...
-
Page 11: Product Overview
Autorun.exe. Follow the instructions provided in the Installation Wizard. Software can also be downloaded from the MadgeTech website at the following link: www.madgetech.com/software-download. 1. Locate the Autorun.exe file on the Software Flash Drive. -
Page 12: Mounting Instruction
Product User Guide Mounting Instructions For best wireless performance, both the RFC1000 and the data loggers should be mounted in the same orientation. This usually means that the external antenna should be pointing straight up. The antenna can pivot to accommodate either a wall mount or a desk mount. -
Page 13: Channel Programming
RFC1000 Channel Programming The RFC1000 transmits data on the 2.4 GHz band and is programmed by default on channel 11. Each wireless Data Logger and RFC1000 has a set of dip switches with which the channel may be programmed. Different wireless channels may be used to create multiple networks in one area, or to avoid wireless interference from other devices. -
Page 14: Deployment & Activation
Step 1: Use the USB Cable, plug the USB end of the cable into an available USB port on the PC. Step 2: Plug the opposite end of the cable into the communication port on the RFCurrent2000A. Step 3: Open the MadgeTech Software. Locate and select the RFCurrent2000A in the Connected Devices panel. -
Page 15: Compliance Information
RFC1000 Compliance Information • “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”... -
Page 16: Troubleshooting Tips
Troubleshooting Tips Why is the wireless data logger not appearing in the software? If the RFCurrent2000A doesn’t appear in the Connected Devices panel, or an error message is received while using the RFCurrent2000A, try the following: • Check that the RFC1000 is properly connected. For more information, see Troubleshooting Interface Cable problems (below).
