MadgeTech RFC1000 Product Information Card

Wireless receiver for the rfot and therm-a-lert
Hide thumbs Also See for RFC1000:
1
2
3
4

Advertisement

Quick Links

Download this manual
Part Name
Interface Type
USB (to PC) / Wireless (to Data Logger)
–20 to +85°C, 0 to 95%RH non-condensed
LED Indicators
Enclosure Materials
ABS Plastic (body), PVC Plastic (antenna)
Dimensions
Enclosure: 3.8" x 1.6" x 0.8" / Antenna: 7.2"
Approvals
FCC ID:OA3MRF24J40MC, IC#: 7693A-24J40MC
4000' max. outdoor - line of sight unobstructed
(To other RFC1000s)
1000' max. indoors - typical urban environment
Transmission Distance
2000' max. outdoor - line of sight unobstructed
(To data loggers)
500' max. indoors - typical urban
Maximum number of
connected data loggers
Frequency
Ingress Protection
Specifications subject to change.
See MadgeTech's terms and conditions at www.madgetech.com
RFC1000
Red & Green
64
2.405GHz - 2.475GHz
IP40
DOC-1276035-00 REV 2 2012.12.13
Product Information Card
RFC1000
Wireless receiver for the RFOT and Therm-A-Lert
RFC1000
Red 485
Dark Blue Pantone 289
Light Blue 58% of Pantone 289

Advertisement

loading
Need help?

Need help?

Do you have a question about the RFC1000 and is the answer not in the manual?

Questions and answers

Related Manuals for MadgeTech RFC1000

Summary of Contents for MadgeTech RFC1000

  • Page 1 2.405GHz - 2.475GHz Ingress Protection IP40 RFC1000 Wireless receiver for the RFOT and Therm-A-Lert Red 485 Specifications subject to change. Dark Blue Pantone 289 See MadgeTech’s terms and conditions at www.madgetech.com Light Blue 58% of Pantone 289 DOC-1276035-00 REV 2 2012.12.13...

  • Page 2: Product Notes

    2000 feet maximum typical outdoors/line of sight, 500 feet maximum typical indoors/urban. The RFC1000 can connect to a maximum of 64 data loggers. The RFC1000 transmits on a frequency of 2.405GHz - 2.475 GHz.

  • Page 3: Mounting Instructions

    Switch the wireless ON / OFF switch back to ‘1’. Deploying and Activating Devices Step 1: Plug the RFC1000 into the USB port on the base station computer. (Additional RFC1000s can be used as repeaters to transmit over greater distances) Step 2: If using multiple RFC1000s plug each one into a wall outlet in the desired locations.
  • Page 4 RFC1000 Rev.2 Product Quick Reference Card o “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”...
