- Page 1 GEMÜ 629 eSyLite Motorized diaphragm valve Operating instructions further information webcode: GW-629...
- Page 2 All rights including copyrights or industrial property rights are expressly reserved. Keep the document for future reference. © GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG 29.06.2021 GEMÜ 629 eSyLite 2 / 41 www.gemu-group.com...
-
Page 3: Table Of Contents
Product compliance ........Mechanical data ..........Duty cycle and service life ......8 Dimensions ............Actuator dimensions without position indic- ator ..............Actuator dimensions with GEMÜ 1215 posi- tion indicator ..........Body dimensions ........... 9 Manufacturer's information ........Delivery ............Transport ............ -
Page 4: General Information
Hot plant components! Working medium The medium that flows through the GEMÜ product. Diaphragm size Uniform seat size of GEMÜ diaphragm valves for different Damage to the product nominal sizes. 1.4 Warning notes Wherever possible, warning notes are organised according to... -
Page 5: Safety Information
1.4435 (BN2), forged body, Δ Fe < turer first. 0.5 % 1.4435, investment casting In cases of uncertainty: 1.4539, forged body 15. Consult the nearest GEMÜ sales office. Electrical connec- tion www.gemu-group.com 5 / 41 GEMÜ 629 eSyLite... -
Page 6: Description
Traceability number Consecutive number 5 Correct use The month of manufacture is encoded in the traceability num- ber and can be obtained from GEMÜ. The product was manu- DANGER factured in Germany. Danger of explosion The operating pressure stated on the product label applies to a media temperature of 20 °C. -
Page 7: Order Data
Spigot ANSI/ASME B36.19M schedule 5s PFA lined Spigot ANSI/ASME B36.19M schedule 40s EN-GJS-400-18-LT (GGG 40.3), Threaded connection PP lined Threaded socket DIN ISO 228 EN-GJS-400-18-LT (GGG 40.3), Threaded socket NPT hard rubber lined www.gemu-group.com 7 / 41 GEMÜ 629 eSyLite... - Page 8 Actuator size 1 in accordance with DIN 11866 HE3, diaphragm size 25 electropolished internal/external Actuator size 3 Ra ≤ 0.6 μm (25 μin.) for media wetted surfaces, 1507 diaphragm size 40 mechanically polished internal GEMÜ 629 eSyLite 8 / 41 www.gemu-group.com...
- Page 9 6 Order data 11 CONEXO Code Without Integrated RFID chip for electronic identification and traceability www.gemu-group.com 9 / 41 GEMÜ 629 eSyLite...
-
Page 10: Order Example
9 Surface 1503 Ra ≤ 0.8 µm (30 µin.) for media wetted surfaces, in accordance with DIN 11866 HE3, electropolished internal/external 10 Actuator version Actuator size 3 diaphragm size 40 11 CONEXO Without GEMÜ 629 eSyLite 10 / 41 www.gemu-group.com... -
Page 11: Technical Data
Therefore the Kv values may exceed the tolerance limits of the stand- ard. The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and dur- ation of use. www.gemu-group.com 11 / 41 GEMÜ 629 eSyLite... - Page 12 Therefore the Kv values may exceed the tolerance limits of the standard. The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and dur- ation of use. GEMÜ 629 eSyLite 12 / 41 www.gemu-group.com...
-
Page 13: Product Compliance
Observe the angle of rotation to achieve an installation for optimized draining Weight: Actuator Actuator version B1 1.0 kg Actuator version 1C 0.8 kg Actuator version 1F 0.94 kg Actuator version 3H 1.4 kg www.gemu-group.com 13 / 41 GEMÜ 629 eSyLite... - Page 14 1.85 0.75 0.58 0.60 0.34 0.78 2.35 0.71 0.55 0.90 0.39 0.79 2.85 0.63 1.45 1.20 0.88 1.66 4.90 1.62 1.32 1.80 0.93 1.62 5.65 1.50 MG = diaphragm size, weight in kg GEMÜ 629 eSyLite 14 / 41 www.gemu-group.com...
-
Page 15: Duty Cycle And Service Life
7.7.2 Emergency power supply module Charging current: MG 8, MG 10, MG 25: max. 0.16 A MG 40: 0.32 A Charging time: approx. 13 min Service life: Guide value at 25 °C ambient temperature, approx. 3 years www.gemu-group.com 15 / 41 GEMÜ 629 eSyLite... -
Page 16: Dimensions
63.0 59.5 134.5 115.0 82.0 204.0 75.0 59.5 134.5 115.0 82.0 228.0 91.0 80.0 167.0 147.5 94.5 Dimensions in mm MG = diaphragm size * CT = A + H1 (see body dimensions) GEMÜ 629 eSyLite 16 / 41 www.gemu-group.com... -
Page 17: Actuator Dimensions With Gemü 1215 Position Indicator
8 Dimensions 8.2 Actuator dimensions with GEMÜ 1215 position indicator 256.0 72.0 61.0 30.0 40.0 237.0 72.0 61.0 30.0 40.0 249.0 72.0 61.0 30.0 40.0 273.0 72.0 61.0 30.0 40.0 Dimensions in mm MG = diaphragm size www.gemu-group.com 17 / 41... -
Page 18: Body Dimensions
Code 60: Spigot ISO 1127/EN 10357 series C/DIN 11866 series B 2) Valve body material Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % Code F4: 1.4539, forged body GEMÜ 629 eSyLite 18 / 41 www.gemu-group.com... - Page 19 Code 17: Spigot EN 10357 series A (formerly DIN 11850 series 2)/DIN 11866 series A Code 60: Spigot ISO 1127/EN 10357 series C/DIN 11866 series B 2) Valve body material Code C3: 1.4435, investment casting www.gemu-group.com 19 / 41 GEMÜ 629 eSyLite...
- Page 20 Code 65: Spigot ANSI/ASME B36.19M schedule 40s 2) Valve body material Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % Code C3: 1.4435, investment casting Code F4: 1.4539, forged body GEMÜ 629 eSyLite 20 / 41 www.gemu-group.com...
- Page 21 Code 37: Spigot SMS 3008 2) Valve body material Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % Code C3: 1.4435, investment casting Code F4: 1.4539, forged body www.gemu-group.com 21 / 41 GEMÜ 629 eSyLite...
- Page 22 MG = diaphragm size n = number of flats 1) Connection type Code 1: Threaded socket DIN ISO 228 2) Valve body material Code 8: EN-GJL-250 (GG 25) Code 37: 1.4408, investment casting GEMÜ 629 eSyLite 22 / 41 www.gemu-group.com...
- Page 23 NPT 1½ 55.0 17.0 Dimensions in mm MG = diaphragm size n = number of flats 1) Connection type Code 31: Threaded socket NPT 2) Valve body material Code 37: 1.4408, investment casting www.gemu-group.com 23 / 41 GEMÜ 629 eSyLite...
- Page 24 MG = diaphragm size 1) Connection type Code 6: Threaded spigot DIN 11851 2) Valve body material Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % GEMÜ 629 eSyLite 24 / 41 www.gemu-group.com...
- Page 25 1) Connection type Code 6K: Cone spigot and union nut DIN 11851 2) Valve body material Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % www.gemu-group.com 25 / 41 GEMÜ 629 eSyLite...
- Page 26 Code 39: 1.4408, PFA lined Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % Code 83: EN-GJS-400-18-LT (GGG 40.3), hard rubber lined Code C3: 1.4435, investment casting GEMÜ 629 eSyLite 26 / 41 www.gemu-group.com...
- Page 27 Code 39: 1.4408, PFA lined Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % Code 83: EN-GJS-400-18-LT (GGG 40.3), hard rubber lined Code C3: 1.4435, investment casting www.gemu-group.com 27 / 41 GEMÜ 629 eSyLite...
- Page 28 Code 8T: Clamp DIN 32676 series C, face-to-face dimension FTF EN 558 series 7, length only for body configuration D 2) Valve body material Code 40: 1.4435 (F316L), forged body Code 42: 1.4435 (BN2), forged body, Δ Fe < 0.5 % Code F4: 1.4539, forged body GEMÜ 629 eSyLite 28 / 41 www.gemu-group.com...
-
Page 29: Manufacturer's Information
3. Do not exceed the maximum storage temperature (see chapter "Technical data"). CAUTION 4. Do not store solvents, chemicals, acids, fuels or similar fluids in the same room as GEMÜ products and their spare Exceeding the maximum permissible pressure. parts. ▶ Damage to the product. -
Page 30: Installation Position
3. Insert the corresponding gasket between the body of the product and the pipe connection. 4. Connect the gasket between the body of the product and the pipe connection using clamps. 5. Re-attach or reactivate all safety and protective devices. GEMÜ 629 eSyLite 30 / 41 www.gemu-group.com... -
Page 31: Installation With Flanged Connection
7. Connect the valve flange and the piping flange using ap- propriate sealing materials and matching bolting. 8. Use all flange holes. 9. Tighten the bolts diagonally. 10. Re-attach or reactivate all safety and protective devices. www.gemu-group.com 31 / 41 GEMÜ 629 eSyLite... -
Page 32: Electrical Connection
24 V supply voltage Digital input OPEN Digital input CLOSED n.c. n.c. n.c. Preferred direction when both digital inputs are present Ordering option Control Preferred direction module A0, Z0 OPEN A1, Z1 CLOSED A2, Z2 OPEN GEMÜ 629 eSyLite 32 / 41 www.gemu-group.com... -
Page 33: Operation
1. Remove the sealing plug 2 from the actuator cover 1 using an appropriate tool. OPEN CLOSED 2. Operate the manual override 3 with the hexagon socket (WAF3). ð Turn clockwise to close the valve. ð Turn anticlockwise to open the valve. www.gemu-group.com 33 / 41 GEMÜ 629 eSyLite... - Page 34 Valve body / actuator damaged Replace valve body/actuator Body of the GEMÜ product is leaking Body of the GEMÜ product is faulty or Check the body of the GEMÜ product for corroded potential damage, replace body if neces-...
-
Page 35: Inspection And Maintenance
5. Depressurize the plant or plant component. 14.3 Removing the diaphragm 6. Actuate GEMÜ products which are always in the same po- 1. Remove actuator A (see chapter "Removing the actuator"). sition four times a year. 2. Unscrew the diaphragm. -
Page 36: Mounting The Compressor
10. Press the diaphragm face tightly onto the backing dia- phragm manually so that it returns to its original shape and fits closely on the backing diaphragm. 11. Align the weir of compressor and diaphragm in parallel. GEMÜ 629 eSyLite 36 / 41 www.gemu-group.com... -
Page 37: Mounting The Actuator
If 3. Check if the compressor is fitted in the guides. no return delivery note is included with the product, GEMÜ 4. Manually screw new diaphragm tightly into the com- cannot process credits or repair work but will dispose of the pressor. -
Page 38: 2006/42/Ec (Machinery Directive)
18 Declaration of Incorporation according to 2006/42/EC (Machinery Directive) Declaration of Incorporation according to the EC Machinery Directive 2006/42/EC, Annex II, 1.B for partly completed machinery GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG Fritz-Müller-Straße 6-8 74653 Ingelfingen-Criesbach, Germany declare that the following product Make: GEMÜ... - Page 39 AD 2000 Note for products with a nominal size ≤ DN 25: The products are developed and produced according to GEMÜ process instructions and quality standards which comply with the requirements of ISO 9001 and ISO 14001. According to Article 4, Paragraph 3 of the Pressure Equipment Directive 2014/68/EU these products must not be identified by a CE-label.
- Page 40 20 Declaration of conformity according to 2014/30/EU (EMC Directive) EU Declaration of Conformity in accordance with 2014/30/EU (EMC Directive) GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG Fritz-Müller-Straße 6-8 74653 Ingelfingen-Criesbach, Germany declare that the product listed below complies with the safety requirements of the EMC Directive 2014/30/EU.
- Page 41 Subject to alteration GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG *88767818* Fritz-Müller-Straße 6-8, 74653 Ingelfingen-Criesbach, Germany 06.2021 | 88767818 Phone +49 (0) 7940 1230 · info@gemue.de www.gemu-group.com...
