OPERATION AND MAINTENANCE MANUAL FOR
Model 70P3 Impulse Wrench is designed for use in assembly operations and is ideally suited to
appliance assembly.
Ingersoll–Rand is not responsible for customer modification of tools for applications on which
Ingersoll–Rand was not consulted.
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING TOOL.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION
IN THIS MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
PLACING TOOL IN SERVICE
Always operate, inspect and maintain this tool in
accordance with American National Standards
Institute Safety Code for Portable Air Tools
(ANSI B186.1).
For safety, top performance, and maximum
durability of parts, operate this tool at 90 psig
(6.2 bar/620 kPa) maximum air pressure at the inlet
with 3/8" (10 mm) inside diameter air supply hose.
Always turn off the air supply and disconnect the
air supply hose before installing, removing or
adjusting any accessory on this tool, or before
performing any maintenance on this tool.
Do not use damaged, frayed or deteriorated air
hoses and fittings.
Be sure all hoses and fittings are the correct size
and are tightly secured. See Dwg. TPD905–1 for a
typical piping arrangement.
Always use clean, dry air at 90 psig
(6.2 bar/620 kPa) maximum air pressure. Dust,
corrosive fumes and/or excessive moisture can ruin
the motor of an air tool.
Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel.
Do not remove any labels. Replace any damaged
label.
The use of other than genuine Ingersoll–Rand replacement parts may result in safety hazards, decreased tool
performance, and increased maintenance, and may invalidate all warranties.
Repairs should be made only by authorized trained personnel. Consult your nearest Ingersoll–Rand Authorized
Servicenter.
Refer All Communications to the Nearest
Ingersoll–Rand Office or Distributor.
 Ingersoll–Rand Company 2000
Printed in U.S.A.
MODEL 70P3
TWIN BLADE IMPULSE WRENCH
03542453
USING THE TOOL
Always wear eye protection when operating or
performing maintenance on this tool.
Always wear hearing protection when operating
this tool.
Keep hands, loose clothing and long hair away from
rotating end of tool.
Anticipate and be alert for sudden changes in
motion during start up and operation of any power
tool.
Keep body stance balanced and firm. Do not
overreach when operating this tool. High reaction
torques can occur at or below the recommended air
pressure.
Tool shaft may continue to rotate briefly after
throttle is released.
Air powered tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions may
be harmful to your hands and arms. Stop using any
tool if discomfort, tingling feeling or pain occurs.
Seek medical advice before resuming use.
Use accessories recommended by Ingersoll–Rand.
Use only impact sockets and accessories. Do not use
hand (chrome) sockets or accessories.
This tool is not designed for working in explosive
atmospheres.
This tool is not insulated against electric shock.
F
Form P7319
Edition 5
E
May, 2000
P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70P3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ingersoll-Rand 70P3

  • Page 1 OPERATION AND MAINTENANCE MANUAL FOR MODEL 70P3 TWIN BLADE IMPULSE WRENCH Model 70P3 Impulse Wrench is designed for use in assembly operations and is ideally suited to appliance assembly. Ingersoll–Rand is not responsible for customer modification of tools for applications on which Ingersoll–Rand was not consulted.
  • Page 2: Warning Label Identification

    WARNING LABEL IDENTIFICATION FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY. WARNING WARNING WARNING Always turn off the air sup- Always wear eye protection Always wear hearing ply and disconnect the air when operating or perform- protection when operating supply hose before install- ing maintenance on this this tool.
  • Page 3: Placing Tool In Service

    (Part No. EQ106S–K400). Lubricate the hex drive and the (Dwg. TPD905–1) output shaft before assembly. SPECIFICATIONS Model Type of Chuck/Drive Free Recommended Torque Range Handle Speed Soft Draw Hard Slam ft–lb (Nm) ft–lb (Nm) 70P3 pistol 3/8” square dr. 7,000 36–56 35–48 (50–76) (48–65)
  • Page 4: Utilisation De L'outil

    À DOUBLE PALETTE MODELE 70P3 NOTE La clé hydropneumatique Modèle 70P3 est destinée aux opérations d’assemblage, et est particulièrement adoptée à l’assemblage des appareillages. Ingersoll–Rand ne peut être tenu responsable de la modification des outils par le client pour les adapter à...
  • Page 5: Le Non Respect Des Avertissements Suivants Peut Causer Des Blessures

    SIGNIFICATION DES ETIQUETTES D’AVERTISSEMENT ATTENTION LE NON RESPECT DES AVERTISSEMENTS SUIVANTS PEUT CAUSER DES BLESSURES ATTENTION ATTENTION ATTENTION Couper toujours l’alimentation Porter toujours une Porter toujours des lunettes d’air comprimé et débrancher le protection acoustique de protection pendant flexible d’alimentation avant pendant l’utilisation de cet l’utilisation et l’entretien de d’installer, déposer ou ajuster...
  • Page 6: Mise En Service De L'outil

    (Réf. No. EQ106S–K400). Lubrifier l’entraîneur hexagonal VIDANGER (Plan TPD905–1) RÉGULIÈREMENT et l’arbre de sortie avant l’assemblage SPÉCIFICATIONS Modèle Poignée à Limiteur/ Vitesse libre Gamme de couples levier Entraînement recommandée pouces tr/mn Serrage Serrage fort élastique Nm 70P3 pistolet 3/8” entr. 7.000 50–76 48–65 carré...
  • Page 7: Uso De La Herramienta

    LLAVES DE IMPULSO DE DOBLE PALETA MODELO 70P3 NOTA La Llave de Impulso Modelo 70P3 está diseñada para operaciones de montaje y resulta especialmente eficaz en el montaje de electrodomésticos. Ingersoll–Rand no aceptará responsabilidad alguna por la modificación de las herramientas efectuada por el cliente para las aplicaciones que no hayan sido consultadas con Ingersoll–Rand.
  • Page 8: Etiquetas De Aviso

    ETIQUETAS DE AVISO AVISO EL HACER CASO OMISO DE LOS AVISOS SIGUIENTES PODRÍA OCASIONAR LESIONES. ADVERTENCIA ADVERTENCIA ADVERTENCIA Cortar siempre el suministro de aire y desconectar la man- Use siempre protección para Use siempre protección ocular los oídos cuando utilice esta guera de suministro de aire cuando utilice esta herramienta antes de instalar, retirar o ajus-...
  • Page 9: Para Poner La Herramienta En Servicio

    (Esq. TPD905–1) accionamiento hexagonal antes del montaje. ESPECIFICACIONES Modelo Tipo de Portabroca/Acciona- Velocidad Libre Gama de par Empuñadura miento recomendada pulg. Retroceso Golpe Fuerte Suave ft–lbs (Nm) ft–lbs (Nm) 70P3 pistola 3/8” pulg. 7.000 36–56 35–48 broca de (50–76) (48–65) inserción...
  • Page 10 IMPULSO DE LÂMINAS DUPLAS MODELO 70P3 AVISO A Chave de Impulso modelo 70P3 é concebida para operações de montagem e é ideal para a montagem de aparelhos. A Ingersoll–Rand não é responsável por modificações feitas pelo cliente em ferramentas nas quais a Ingersoll–Rand não tenha sido consultada.
  • Page 11 IDENTIFICAÇÃO DO RÓTULO DE ADVERTÊNCIA ADVERTÊNCIA O NÃO CUMPRIMENTO DAS SEGUINTES ADVERTÊNCIAS PODE RESULTAR EM FERIMENTOS. ADVERTÊNCIA ADVERTÊNCIA ADVERTÊNCIA Use sempre óculos de Use sempre protecção contra o Desligue sempre a alimentação protecção quando estiver ruído ao operar esta ferramenta. de ar e desconecte a mangueira operando ou executando algum de alimentação de ar antes de...
  • Page 12 Lubrifique o comando hexagonal e o eixo de saída antes de (Desenho TPD905–1) montar. ESPECIFICAÇÕES Modelo Tipo de Punho Encabadouro/ Velocidade Livre Intervalo de Torque Comando Recomendado pol. Aperto Batimento Ligeiro Duro Nm (pés–lb) Nm (pés–lb) 70P3 pistola 3/8” 50–76 48–65 quadrada (36–56) (35–48)
  • Page 13 (Dwg. TPA1560–2)
  • Page 14 Nameplate 29 Rotor ........70P3–53 for model 70P3 ... . .
  • Page 15 EQ106S–288 80 Hexagon Wrench ......70P3–900 Back–up Ring ..... . .
  • Page 16: Maintenance Section

    13. Position a new Mechanism Cover Gasket on the Using the special Tee Wrench furnished in the Tool Motor Housing and install the assembled mechanism Kit (Part No. 70P3–199), remove the Oil Plug (58) on the rotor shaft. and Oil Plug Seal (59).
  • Page 17 Insert the pins of the spanner plug from the tor bore in a horizontal position and handle pointing No. 70P3–199 Tool Kit into the two holes in the down. Using a plastic hammer, lightly tap the Hous- Housing Cap (44). Using a wrench on the plug, ing surrounding the motor bore to loosen the motor.
  • Page 18 MAINTENANCE SECTION ASSEMBLY General Instructions 1. When grasping a tool or part in a vise, always use leather–covered or copper–covered vise jaws to pro- tect the surface of the part and help prevent distor- tion. This is particularly true of threaded members and housings.
  • Page 19 MAINTENANCE SECTION 12. Using an arbor press and a piece of tubing that con- 15. Coat each Vane (30) with a thin film of oil and insert tacts the outer ring of the bearings, press the Front a Vane into each of the rotor vane slots with the End Plate Bearing (32) into the Front End Plate (31) straight edge of the Vane outward.
  • Page 20 Spring Guide (51) into the central opening of the O–ring installer furnished with the Tool Kit (Part No. 70P3–199). Place the Spring Guide Seal (52) on the tapered end of the installer and roll the Seal up the taper and into the groove on the large body of the Spring Guide.
  • Page 21 MAINTENANCE SECTION The Torque Adjustment Screw (39) can only be installed from the liner end of the Mechanism Cover BACK–UP RING (38). If the Torque Adjustment Screw was removed, proceed as follows: STOP CAP O–RING a. Insert a 1.5 mm hex wrench into the threaded hole for the Torque Adjustment Screw from the oil OIL STOP CAP plug end of the Cover.
  • Page 22 MAINTENANCE SECTION 15. Grasp the flats of the Housing in vise jaws with the 17. Install the Housing Cap (44) and using the spanner output spindle downward. Remove the Rear Liner plug furnished in the Tool Kit, tighten the Cap Cover Assembly and put grease in the central between 58–65 ft–lb (78–88 Nm) torque.
  • Page 23 NOTES...
