Nordic - 3 Drawer Chest
Assembly Instructions
Dimensions
Width : 43,7 cm
Depth : 39,7 cm
Height : 56,2 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
344003050
- Please keep for future reference
1736603
0845 640 30 30
- 07-11-2013
Advertisement
Table of Contents
Related Manuals for Argos Nordic 3 Drawer Chest
Summary of Contents for Argos Nordic 3 Drawer Chest
- Page 1 Nordic - 3 Drawer Chest Assembly Instructions - Please keep for future reference 1736603 Dimensions Width : 43,7 cm Depth : 39,7 cm Height : 56,2 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 30 30 - 07-11-2013 344003050...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Do not stand or put weight on components and tools listed on the product, this could cause pages 3 and 4. damage.
- Page 3 If you have damaged or missing components, call Components - Panels the Argos Customer Helpline: 0845 640 30 30 Please check you have all the panels listed below 437x397x15 mm Plinth, back V155859 383x60x15 mm P155865 Side, right Plinth, front...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 30 30 Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fix the drawer sides 9 to the drawer back 10 as shown, using screws R Step 2 Knock the dowels B into the holes indicated on the drawer sides 9 using a small hammer Step 3 Slide the drawer bottom 11 into the drawer sides 9...
-
Page 6: Table Of Contents
Assembly Instructions Step 5 Push the drawer fronts 7 and 8 onto the drawer sides 9 as shown Push cams C into the holes indicated. Arrow pointing toward the front. Turn the cams C to the right to fix the fronts 7 and 8 Step 6 Important! -
Page 7: Step
Assembly Instructions Step 8 Screw the bolts C into the holes indicated on the top 1. Step 9 Screw the bolts into the holes indicated on the sides 2 and 3. Fix the angles V on to the sides 2 and 3 using screws E. -
Page 8: Push Cams C Into The X
Assembly Instructions Step 12 Knock down the dowels A into the holes indicated on the back plinth 4 Step 13 Fix the back plinth 4 to sides 2 and 3 . Push the cams C into the holes indicated on the back plinth 4. -
Page 9: Important! Make Sure The
Assembly Instructions Step 16 Place the back 6 into the rebates in the sides 2 and 3. Important! Make sure the angle between the top 1 and the sides 2 an 3 is 90 when this is attached Fix the back 6 to the sides 2 and 3, the top 1 and the rail using nails i.
