New Charlie TV Unit
Assembly Instructions
Dimensions
Width - 119 cm
Depth - 39 cm
Height - 34 cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
- Please keep for future reference
609/7024
609/7031
609/7048
Version2 Date: 30/08/12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos New Charlie TV Unit
Summary of Contents for Argos New Charlie TV Unit
- Page 1 New Charlie TV Unit Assembly Instructions 609/7024 - Please keep for future reference 609/7031 609/7048 Dimensions Width - 119 cm Depth - 39 cm Height - 34 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand on the product, • We do not components and tools listed on this could cause damage. recommend the pages 2 and 3. - Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Top panel (119 x 39cm) Bottom panel (109.6 x 38.7cm) Finished front edge Right side panel Left side panel (38.8 x 29.8cm) (38.8 x 29.8cm)
- Page 4 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. in some cases mor may be supplied than are required. 39mm Locking pin x 8 43mm Locking pin x 6 15mm Locking nut x 14 30mm Dowel x 7 40mm Dowel x 4 50mm Screw x 3...
- Page 5 Assembly Instructions Step 1 Attaching left side panel Insert Dowels into the Middle panel & Shelf Screw Locking pins into the Middle panel Note: Insert Locking pins as far as shown. Do not over tighten. Position Middle panel onto the Shelf Insert 2 Locking nuts into the Shelf Use a screwdriver to turn...
- Page 6 Assembly Instructions Step 1 - continued Insert Dowels & into the Left side panel Screw Locking pins into the Left side panel Note: Insert Locking pins as far as shown. Do not over tighten. Position Left side panel onto the Shelf Insert 2 Locking nuts Finished into the Shelf...
- Page 7 Assembly Instructions Step continued Position Bottom panel onto the Left side panel Insert 2 Locking nuts Finished front edge into the Bottom panel Use a screwdriver to turn Locking nuts clockwise to lock. Bottom panel onto the unit. Fix Feet to Bottom panel using Screw...
- Page 8 Assembly Instructions Step 3 - continued Position Right side panel onto the Bottom panel Finished Insert 2 Locking nuts front edge into the Bottom panel Use a screwdriver to turn Locking nuts clockwise to lock. Step 4 Attaching top panel Screw Locking pins into the Top panel Note: Screw Locking pins...
- Page 9 Assembly Instructions Step 4 - continued Note: It would be useful to ask someone to help you at this stage. Place a small amount of Glue onto the joint’s surfaces. Carefully position Top panel onto the unit. Insert 6 Locking nuts into Finished the unit.
