About the ConnectCore 8M Mini development board
x5 GPIOs
l
CAN FD (through SPI interface)
l
RS-485
l
PCI Express Mini Card slot supporting half- and full-size cards, with USB, PCIe and Micro-
l
SIM connection.
Audio interfaces:
l
x1 3.5 mm headphone jack
o
x1 3.5 mm microphone jack
o
x2 speaker outputs
o
x1 line-out output
o
x2 line-in inputs
o
x2 XBee sockets, one supporting XBee cellular
l
x2 SMA antenna connectors, one for the on-module antenna and another for the Mini PCIe
l
card
User interfaces:
n
x2 user buttons
l
x3 user LEDs
l
Dimensions:
n
210 x 130 mm
l
Note * Only one display interface can be enabled at a time.
