FRU (Field Replaceable Unit) LIST
This chapter gives you the FRU (Field Replaceable Unit) listing in global configuration of AL1513. Refer to this chapter
whenever ordering for parts to repair or for RMA (Return Merchandise Authorization).
NOTE: Please not WHEN ORDER FRU PARTS, that you should check the most up-to-date information available on your
regional web or channel (http://aicsl.acer.com.tw/spl/). For whatever reasons a part number change is made, it will not be
noted in the printed Service Guide. You MUST use the local FRU list provided by your regional Acer office ot order FRU
parts for repair and service of customer machines.
Note: To scrap or to return the defective parts. You should follow the local government ordinance or regulations on how best
to dispose it, or follow the rules set by your regional Acer office on how to return it.

PART LIST

CATEGORY
CASE/COVER/BRACKET
ASSEMBLY
Cable
Cable
Cable
Cable
Cable
CASE/COVER/BRACKET
ASSEMBLY
CASE/COVER/BRACKET
ASSEMBLY
CASE/COVER/BRACKET
ASSEMBLY
CASE/COVER/BRACKET
ASSEMBLY
CASE/COVER/BRACKET
ASSEMBLY
CASE/COVER/BRACKET
ASSEMBLY
CASE/COVER/BRACKET
ASSEMBLY
PARTNAME
HRN ASS'Y 8P 280mm
UL2651#28FW08E23-0F-D
LVDS FFC 30P cable
VGA cable black
Euro power cord black
UK power cord black
Swiss power cord black
COVER,HINGE
COVER,BACK
BASE
STAND, LE1710
BRACKET,FINGER
HINGE, LE1710
CHASSIS (main metal part)
HRN ASS'Y 8P 280mm
UL2651#28FW08E23-0F-D
HRN LVDS FFC 30P 240mm
CABLE,D-SUB 15P MALE 6FT
BLACKSZ4120955B
PWR CORD 6A/250V BLK 6FT VDE
PWRCORD 6A/250V BLK 6FT UK
PWRCORD 6A/250V BLK 6FT SWISS
COVER,HINGE, LE1710
COVER,BACK, LE1710
BASE, LE1710
STAND, LE1710
BRACKET,FINGER, LE1710
HINGE, LE1710
CHASSIS, LE1710
41
Chapter 6
DESCRIPTION
