Chassis*1
PCBA Power Board *1
INSULATOR PC,MYLAR
SCREW (PW 3*6,M,ZN) *3
PCBA I/F BOARD *1
CABLE 30P FFC
HRN ASS'Y 8P
SCREW (PW 3*6,M,ZN) *3
PCBA Control Board *1
SCREW (PW 3*4,M,ZN) *2
INL Panel*1
SCREW (PW3x4,M,ZN)*4
FFC(30pin)*1
TAPE,ACE#LP1701(40x20mm)*1
INSULATOR PC#LE1710
Insert B/L jack*4
EMI shield Tape*2
28
