Symbol:

CN103

CN101

U102

X102

U104

U105

CN102

U103

U106

X101

CN105

U101

Component:

LVDS connector

Connector to power BD

5V to 1.8V regulator

Crystal to scaler

Scaler "TSU16AK"

MCU "Winbond"

D-sub connector

DDC

EEPROM

Crystal to MCU

Connector to control BD

5V to 3.3V regulator
