Chapter 1 Monitor Features - Acer AL1716 Service Manual

Hide thumbs

Advertisement

Table of Contents
LCD Panel
Signal
Display Color
Dot Clock
Max. Resolution
Plug & Play
EPA ENGERGY STAR
Input Connector
Input Video Signal
Maximum Screen Size
Power Source
Environmental Considerations
Weight (Net)
Dimension
MONITOR FEATURES
Driving System
Size
Pixel pitch
Viewable angle
Brightness
Contrast Ratio
Response Time
Video
Separate Sync.
H-Frequency
V-Frequency
ON MODE
OFF MODE
Horizontal
Vertical
17"
0.264mm (H) x 0.264mm (V)
140゚(H), 130 ゚(V)
300cd/m
(typ.)
2
500:1 (typ.)
12ms (typ.)
RGB Analog Interface (Analog only model)
H/V TTL
31.5KHz to 60.241KHz
56Hz to 75Hz
6bits+FRC
80MHz
1024 x 768 @75Hz
VESA DDC 1/2B
< 35W
<5W
D-Sub 15pin
Three-Pronged Pin
Analog: 0.7Vp-p (Standard), 75 OHM,
Positive (Analog-Only Model)
338 mm
270 mm
100~240VAC, 50~60Hz
Operating Temp: 5℃ to 35℃
Storage Temp: -20℃ to 60℃
Operating Humidity: 5% to 95%
4.3Kg
343.4 (W) x 351.4 (H) x 159.8 (D) mm
10
TFT Color LCD
