ADJUSTING THE MONITOR
1.) Main OSD Menu
a. Outline
b. Description for OSD
Main
Sub Menu
Menu Icon
Item
Contrast
Brightness
Phase
Clock
H. Position
Sub Menu
Description
Icon
Contrast from digital register
Backlight Adjustment
Adjust picture phase to reduce
horizontal line noise
Adjust picture clock to reduce
vertical line noise
Adjust picture horizontal
position
Adjustment
Range
0-100
0-100
0-100
0-100
0-100
22
Reset Value
50
100
Do auto config
Do Auto Config
Do Auto Config
