OPERATION INSTRUCTIONS
Press the power button to turn the monitor on or off. The other control buttons are located on the front of the monitor. By
changing these settings, the picture can be adjusted to your personal preferences.
The power cord should be connected.
Connect the video cable from the monitor to the VGA Card.
Press the power button to turn on the monitor, the power indicator will light up.
Front Panel Control
No
Symbol
5 4 3 2
20
Chapter 2
1
