Power key/LED
2
Menu/Enter
3
>
4
<
5
Auto/Exit
NOTES
Do not install the monitor in a location near heat sources such as radiators or air ducts, or in a place subject to direct
sunlight, or excessive dust or mechanical vibration or shock.
Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your
monitor.
For maximum protection, repackage your monitor as it was originally packed in the factory.
To keep the monitor looking new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth
lightly dampened with a mild detergent solution. Never use strong solvents such as thinner, benzene, or abrasive
cleaners, since these will damage the cabinet. As a safety precaution, always unplug the monitor before cleaning it.
Press this button to turn the monitor on or off
LED Green – Power On mode
LED Orange – Off mode
Activate OSD menu when OSD is off or activate/de-activate adjustment function when
OSD is ON or Exit OSD menu when in Volume Adjust OSD status.
1. Activates the volume control when the OSD is OFF.
2. Navigate through adjustments icons when OSD is ON.
3. Adjust a function when function is activated.
1. Activates the volume control when the OSD is OFF.
2. Navigate through adjustments icons when OSD is ON.
3. Adjust a function when function is activated.
1. When OSD menu is in active status, this button will act as EXIT (exit OSD menu)
2. When OSD menu is in off status, press this button for 2seconds to activate the "Auto
Adjustment" which is used to set the H.Pos., V Pos., Clock and Phase.
