MODEL NO. 602355
DEVYN UPHOLSTERED BUNK BED
RH Baby&Child
2900 North MacArthur Dr.
Tracy, CA 95376, USA
1-800-762-1751
Distributed in Canada by:
RH Canada, Inc.
1500-1055 West Georgia St.,
Vancouver, British Columbia V6E 4N7
△ !
WARNING: Read all instructions before assembling this product.
KEEP INSTRUCTIONS FOR FUTURE USE.
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to the address
above. Include the product model number, color, and a brief description of the part. Or call 1-800-762-1751.
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning.
Dust often using a clean, soft, dry cloth. Vacuum to remove dust.
If bunk bed is to be stored, store in a cool, dry place and carefully package all original hardware to protect from loss.
Tools needed: Key Wrench (included).
Two people are recommended for assembly.
When inserting bolts, turn clockwise until tight. Then loosen 1/2 - 3/4 of a turn.
After bed is completely assembled, return to each bolt and tighten.
Page 1 / 7
Advertisement
Table of Contents
Related Manuals for RH Baby&child DEVYN 602355
Summary of Contents for RH Baby&child DEVYN 602355
- Page 1 MODEL NO. 602355 DEVYN UPHOLSTERED BUNK BED RH Baby&Child 2900 North MacArthur Dr. Tracy, CA 95376, USA 1-800-762-1751 Distributed in Canada by: RH Canada, Inc. 1500-1055 West Georgia St., Vancouver, British Columbia V6E 4N7 △ ! WARNING: Read all instructions before assembling this product. KEEP INSTRUCTIONS FOR FUTURE USE.
- Page 2 Follow the information on the WARNING label attached to the upper bunk end structure and on the box. DO NOT REMOVE WARNING LABEL FROM BED. Always use the specified mattress size, mattress support, or both to help prevent the likelihood of entrapment or falls.
- Page 3 (1) Headboard Panel – 1 pc. (2) Footboard Panel – 1 pc. (3) Side Rail – 2 pcs. (4) Front Guardrail – 1 pc. (5) Back Guardrail – 1 pc. (6) Bed Foot – 4 pcs. Page 3 / 7...
- Page 4 (7) Platform – 4 pcs. (8) Platform Slat – 10 pcs. (9) Ladder – 1 pc. PART ITEM DESCRIPTION QTY. Threaded Rod 16 pcs. Curved Washer 16 pcs. 16 pcs. Big Screw (3cm) 12 pcs. Wrench 1 pc. Wood Peg 4 pcs.
- Page 5 Attach Bed Feet (6) to Headboard Panel (1) and repeat the procedure with Footboard Panel (2). Attach Side Rails (3) to Headboard Panel (1). Insert the Wood Pegs (F) into the second hole on Side Rails (3), and insert the Threaded Rods (A), Curved Washer (B) and Nut (C) into the other two holes on Side Rails (3).
- Page 6 Lay the Platform Slats (8) in between the Side Rails (3) and Guardrails (4) and (5). : Lay the Platforms (7), then tighten with Big Screws (D). Attach Ladder (9) to Front Guardrail (4), then tighten with Small Screws (G). Page 6 / 7...
- Page 7 DEVYN UPHOLSTERED BUNK BED – ASSEMBLY INSTRUCTIONS Install Mattress: Step 9: MATTRESS SPECIFICATIONS FOR TOP BUNK: The following size mattress and foundation are specified for use with this bunk bed: MATTRESS DIMENSION SPECIFICATIONS FOR TOP BUNK Twin-Over-Twin bunk: 75" long x 38" wide x 7" high Full-Over-Full bunk: 75"...
