- Page 1 User Manual BG-UHD-DA2X8 HDMI 2.0 2x8 Splitter with Audio Breakout and 4K to 1080P Down-Scaling...
- Page 2 All Rights Reserved Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment. Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Packing List ......................2 2. Technical Specification ....................3 3. Panel Description ......................5 3.1 Front Panel ......................5 3.2 Rear Panel ......................6 4. System Connection ..................... 7 4.1 Usage Precaution .................... -
Page 5: Product Introduction
1. Product Introduction Thanks for choosing the HDMI 2.0 2x8 Splitter, which can distribute either one of two HDMI inputs to eight outputs. The splitter supports HDMI video resolution up to 4K@60Hz 4:4:4, 1080P 3D and multichannel audio formats. Except passing EDID information from the display, there are multiple built-in EDID settings can be selected by the 4-pin DIP switch on the rear panel. -
Page 6: Packing List
1.2 Packing List 1x HDMI 2.0 2x8 Splitter 2x Mounting Ears with 4 Screws 4x Plastic Cushions 1x Power Adapter (12V DC 1A) 1x User Manual Note: Please contact your distributor immediately if any damage or defect in the components is found. -
Page 7: Technical Specification
2. Technical Specification Video Input Input (2) HDMI Input Connector (2) Female type-A HDMI HDMI Input Resolution Up to 4Kx2K@60Hz 4:4:4 8bit HDMI Standard HDCP Version Supported Video Output Output (8) HDMI Output Connector (8) Female type-A HDMI HDMI Output Resolution Up to 4Kx2K@60Hz 4:4:4 8bit HDMI Standard Supported... - Page 8 >70dB, 10KHz sine at 0dBFS level (or max level before Crosstalk Isolation clipping) < 0.3dB, 1KHz sine at 0dBFS level (or max level before L-R Level Deviation clipping) Frequency Response <± 0.5 dB 20Hz ~ 20KHz Deviation 1K ohm and higher (supports 10x paralleled 10k ohm Output Load Capability loads) Stereo Channel...
-
Page 9: Panel Description
3. Panel Description 3.1 Front Panel ① POWER LED: The LED illuminates red when power is applied. ② OUTPUT LEDs: The LED illuminates green when there is HDMI output on the corresponding channel. ③ SOURCE Button and LEDs: Press the button to switch to next source device, and then the corresponding input LED will illuminate green. -
Page 10: Rear Panel
mute mode if the displays is already in the mute mode. ⑧ EDID: 3-pin DIP Switch for the Extended Display Identification Data (EDID) value setting. Please refer to the 5.EDID Management for more details. ⑨ FW: Micro-USB port for firmware upgrade. Note: Only the displays which support CEC can be controlled by DISPLAY ON, DISPLAY OFF, VOLUME UP and VOLUME DOWN buttons. -
Page 11: System Connection
4. System Connection 4.1 Usage Precaution Make sure all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets, and power cords should be insulated and safe. -
Page 12: Edid Management
5. EDID Management The Extended Display Identification Data (EDID) is used by the source device to match its video resolution with the connected display. By default, the source device obtains its EDID from the first connected display. Meanwhile, since the displays with different capabilities are connected to the splitter, the 3-pin DIP switch on the front panel and the 4-pin DIP switch on the rear panel can be used in combination to set the EDID to a fixed value to ensure the compatibility in video resolution. - Page 13 Switch Status Video Resolution Audio Format 0000 Obtains EDID from the display connected to the HDMI output port 1. 0001 Obtains EDID from the display connected to the HDMI output port 2. 0010 Obtains EDID from the display connected to the HDMI output port 3. 0011 Obtains EDID from the display connected to the HDMI output port 4.
- Page 14 “BOOTDISK” U-disk. Reopen the U-disk to check the filename “READY.TXT” whether automatically becomes “SUCCESS.TXT”, if yes, the user defined EDID was imported into the splitter and saved as its corresponding EDID ID successfully. Remove the USB cable, and then reboot the splitter. The new EDID now can be invoked via the 4-pin DIP switch directly.
-
Page 15: Video Resolution Down-Scaling
6. Video Resolution Down-scaling The product supports video resolution down-scaling, the 4K input can be automatically degraded to 1080P output for compatibility with 1080P display, shown in the below chart. Input Output Color Resolution Refresh Downscale 1080P Specs Space 3840x2160 4:4:4 Support 1080P@60Hz 4:4:4... -
Page 16: Firmware Upgrade
7. Firmware Upgrade Please follow the below steps to upgrade firmware by the Micro-USB port: 1) Connect the splitter to the PC with USB cable. 2) Power on the splitter, and then the PC will automatically detect a U-disk named of “BOOTDISK”. -
Page 17: Panel Drawing
8. Panel Drawing 324 mm... -
Page 18: Troubleshooting And Maintenance
9. Troubleshooting and Maintenance Problems Potential Causes Solutions The connecting cables may Check whether the cables not be connected correctly are connected correctly and Color losing or no video or it may be broken. in working condition. signal output in HDMI The display is not Make sure the resolution of display. -
Page 19: Customer Service
10. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is one year. 2) Scope These terms and conditions of Customer Service apply to the customer service provided for the products or any other items sold by authorized distributor only. -
Page 20: Warranty Information
11. Warranty Information Second Year Assurance BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1. -
Page 21: Mission Statement
BZB Gear catalog. You’ll notice comparably lower prices with BZB Gear solutions, but the quality of the products is on par with the top brands in the industry. The unparalleled support from our team is our way of showing we care for every one of our customers.
